For High-Speed Head, see Section 5-3-1 "Transfer Head Assembly Replacement." For Multi-Purpose Head, see Section 5-5-2 "Replacing a Set of Head Units." Remove the grease hose. 3 4 Allen key 3 mm Screw…
Tools
Jigs
5-1-9 X-axis Linear Rail Replacement
Main BodyMachine Part Replacement
This section describes the procedures for replacing the X-axis linear rails.
Total Time Part Weight
10
Assembly/AdjustmentRemoval/Disassembly
120
Straight edge 1500 mm
Block gauge 35 mm
Block gauge 85 mm
Min.
6040
Phillips screwdriver #2
Slotted screwdriver #1
Allen key 3 mm
Allen key 4 mm
Wrench 7 mm
Magnetic stand
Dial gauge
Iron plate
Oil stone
Cloth
Teaching
Min. Min. kgs.
220
Min.
Dange
r
Warning
Caution
EJM8A-E-SMA050109-A01-00
Page 5-1-9-1
For High-Speed Head, see
Section 5-3-1
"Transfer Head Assembly
Replacement."
For Multi-Purpose Head,
see Section 5-5-2
"Replacing a Set of Head
Units."
Remove the grease hose.
3
4
Allen key 3 mm
Screw M4 4 pcs.
2
1
項目(ITEM)
Remove the feeder cover
.
Machine Part Replacement Main Body
Remove the head.
Phillips screwdriver #2
Screw M4 2 pcs.
備考(REMARK)
Switch off the power and the air supply.
1
2
EJM8A-E-SMA050109-A01-00
Page 5-1-9-2
6
7
8
Remove the head plate.
項目(ITEM) 備考(REMARK)
Machine Part Replacement Main Body
5
Remove the linear rail.
Allen key 3 mm
Screw M8 x 18 26 pcs.
Allen key 3 mm
Allen key 4 mm
Screw M4 x 12 16 pcs.
Small flat round M4
16 pcs.
Screw M5 2 pcs.
Cloth
Oil stone
Apply oil stone to the new linear rail
softly.
After removing the linear rail,
clean the linear rail mounting section.
Do not shock the sliders.
EJM8A-E-SMA050109-A01-00
Page 5-1-9-3
