Do not remove the bars. Tools and Specifications 12 Allen key 5 mm Screw M3 6 pcs. Remove the screws holding the support- unit upper-limit determining bars. 11 Insert a 15-mm-thick bar behind the support-unit upper-limit…

100%1 / 1093
Tools and Specifications
Allen key 3 mm
Screw M4 4 pcs.
5
8
7
Item
6
Phillips screwdriver 2 pcs.
Round cross-head screw
M6 4 pcs.
Tools and Specifications
Remove the lower chute from the rear side of the selected stage.
Allen key 4 mm
Screw M5x12mm 4 pcs.
Thick washer 4 pcs.
Remark
Tools and Specifications
Remove the lower cover from the rear side of the selected stage.
Remove the ceiling from the box.
Tools and Specifications
Machinery Part Replacement Board Holder Unit
Remove the air tubs from the support plate and the sub plate cylinders.
Chute holding
section (Left)
Chute holding
section (Right)
EJM8A-E-SMA050201-A01-00
Page　5-2-1-3
Do not remove the bars.
Tools and Specifications
12
Allen key 5 mm
Screw M3 6 pcs.
Remove the screws holding the support-
unit upper-limit determining bars.
11
Insert a 15-mm-thick bar behind the support-unit upper-limit determining bars.
Tools and Specifications
15-mm-thick metal bar
(160 mm to 200 mm)
2 pcs.
Tools and Specifications
Remark
100-mm block
or equivalent
Raising the sub plate by hand, insert a 100-mm block or equivalent.
Allen key 2.5 mm
Screw M3 6 pcs.
Tools and Specifications
10
Block:
should be enough to support the sub
plate.
Move the sensor outwards.
9
Machinery Part Replacement Board Holder Unit
Item
Ex
EJM8A-E-SMA050201-A01-00
Page　5-2-1-4
Pull out the support table. ・Be careful not to damage the cylinder
joint
and the dog, which are moved in Step 8.
・Do not loosen the table shaft.
parallelism of the table will become out.
Tools and Specifications
Replace the cylinder. ・Do not loosen the shaft. Otherwise
Wrench 30 mm
Box wrench 30 mm
13
Remove the block.
Tools and Specifications
Lower the sub plate.
Tools and Specifications
holding screws.
Allen key 5 mm
Screw M6 4 pcs.
16
Remove the cylinder holding nut.
14
Remove the support-plate cylinder
15
Tools and Specifications
・
Be careful of interference of the sensor
Item Remark
Machinery Part Replacement Board Holder Unit
Shafts
EJM8A-E-SMA050201-A01-00
Page　5-2-1-5
