Phillips screwdriver #2 Screw M4 2 pcs. Tools and Specifications Remark Remove the sensors. 2 1 Item Remove the feeder cover. Switch off the main power. Machinery Part Replacement Board Holder Unit Tools and Specificatio…
Kgs
.
Total Time
Weight o
f
Part
15
min
.
Removal
Disassembl
y
A
ssembly
A
d
j
ustment
Teaching
min.7 min. 8 min.
・Tools
Machinery Part Replacement Board Holder Unit
This section describes the procedures for replacing the upper and the lower limit sensors for the support plate.
5-2-2
Support Plate Upper and Lower Limit Sensor Replacement
Phillips screwdriver #2
Allen key 2.5 mm
None
・Jig
Dange
r
Warning
Caution
EJM8A-E-SMA050202-A01-00
Page 5-2-2-1
Phillips screwdriver #2
Screw M4 2 pcs.
Tools and Specifications
Remark
Remove the sensors.
2
1
Item
Remove the feeder cover.
Switch off the main power.
Machinery Part Replacement Board Holder Unit
Tools and Specifications
Tools and Specifications
Tools and Specifications
3
4
Remove the sensor connector.
Allen key 2.5 mm
Screw M3 2 pcs.
Lower limit
sensor
Upper limit
sensor
Do not loosen.
EJM8A-E-SMA050202-A01-00
Page 5-2-2-2
Item
Phillips screwdriver #2
Screw M4 2 pcs.
Tools and Specifications
Switch on the main power.
Tools and Specifications
Put the feeder cover back on.
Allen key 2.5 mm
Screw M3 2 pcs.
Replace the sensors.
8
7
6
5
Tools and Specifications
Place the cable in position and connect
Tools and Specifications
the connector.
Machinery Part Replacement Board Holder Unit
Remark
Lower limit
sensor
Upper limit
sensor
Do not loosen
EJM8A-E-SMA050202-A01-00
Page 5-2-2-3
