Tools and Specifications Tools and Specifications Phillips screwdriver #2 Screw M4 2 pcs. Remove the feeder cover . Switch off the main power and air supply. Tools and Specifications Tools and Specifications Remove the c…
・Tools
・Jig
Phillips screwdriver #2
Allen key 2.5 mm
None
Board Holder Unit
This section describes the procedures for replacing the sensor for the ascent of the support-pin plate box.
5-2-3
Support-Pin Plate Box Ascent Sensor Replacement
Machinery Part Replacement
min.
Weigh
t
o
f
Part
15 min. 20 min.
35
min
.
Kgs
.
Removal
Disassembly
A
ssembl
y
Adjustment
Teaching Total Time
Dange
r
Warning
Caution
EJM8A-E-SMA050203-A01-00
Page 5-2-3-1
Tools and Specifications
Tools and Specifications
Phillips screwdriver #2
Screw M4 2 pcs.
Remove the feeder cover
.
Switch off the main power and air supply.
Tools and Specifications
Tools and Specifications
Remove the connectors.
1
Item Remark
4
3
2
Pull the cable out of the duct.
Machinery Part Replacement Board Holder Unit
1
2
EJM8A-E-SMA050203-A01-00
Page 5-2-3-2
Allen key 2.5 mm
Screw M3 2 pcs.
Place a new sensor in position.
Put the cable back in the duct.
Connect the connector.
Tools and Specifications
Tools and Specifications
Allen key 2.5 mm
Screw M3 2 pcs.
Tools and Specifications
Machinery Part Replacement Board Holder Unit
RemarkItem
8
7
6
5
Remove the sensor.
Tools and Specifications
EJM8A-E-SMA050203-A01-00
Page 5-2-3-3
