Machinery Part Replacement Board Holder Unit Remarks Item Switch on the main power and air supply. ｶﾊﾞｰ達 From 0.49MPa to 0.54MPa 17 1 2 EJM8A-E-SMA050204-A01-00 Page 5-2-4-6
Machinery Part Replacement Board Holder Unit
Remarks
Item
Remove the support-plate change plate.
Remove the blocks, which were placed
under the support-plate changed in Step
5.
Connect the cylinder tubes.
3-000118,000119
Put the lower rear cover back on.
ｶﾊﾞｰ達
Phillips screwdriver #2
Round cross-head screw
6 mm 4 pcs.
Put back the rear chute.
ｶﾊﾞｰ達
Allen key 4 mm
Screw M5x12mm 4 pcs.
Thick washer 4 pcs.
13
14
15
16
Chute holding
section (left)
Chute holding
section (right)
EJM8A-E-SMA050204-A01-00
Page 5-2-4-5
Machinery Part Replacement Board Holder Unit
Remarks
Item
Switch on the main power and air supply.
ｶﾊﾞｰ達
From 0.49MPa
to 0.54MPa
17
1
2
EJM8A-E-SMA050204-A01-00
Page 5-2-4-6
Machinery Part Replacement
This section describes the procedures for replacing the transfer head assembly.
・Tools
Phillips screwdriver #1
Phillips screwdriver #2
Allen key 5 mm
Pipe
Nipper
・Jig
Refer to teaching sections
of this manual.
Be sure to remove the nozzles and the nozzle holders beforehand.
[Check before replacement!!]
All head driver software versions should be the same.
If alll the versions are not the same, trouble may occur.
L
ight Transfer-Head Assembly (8-nozzle type
)
5-3-1 Transfer Head Assembly Replacement
Caution
Dange
r
Warning
Assembly/Adjustment
30 min.
Teaching
77 min.
Removal/Disassembly
10 min.
Total Time
117 min.
Part Weight
k
g
s.
10
Li
g
ht Transfer-Head Assembl
y
(
8-nozzle t
yp
e
)
5-3
EJM8A-E-SMA050301-A01-00
Page5-3-1-1
