Machinery Part Replacement Remarks L ight Transfer-Head Assembly (8-nozzle type ) Item How to install the motor: Install the Z-axis motor, positioning the set-screw hole of D above 90 degrees away from the mark on the mo…

100%1 / 1093
Machinery Part Replacement
Remarks
L
ight Transfer-Head Assembly (8-nozzle type
)
Item
Remove the motor holdin
g
screws.
Allen key 3 mm
Screw M4x16L 2 pcs.
Remove the motor from the plate.
Z-axis motor removed from the machine Allen key 2.5 mm
Screw M3x8L 2 pcs.
Magic marker
A
ppl
y
a small amount of
g
rease to the
Tighten the set-screw, aligning the
joint of the Z-axis motor.
set-screw hole with the D-shaped cut
on the motor shaft.
Allen key 2 mm
MP Grease 2S
Relationship of motor shaft and joint positions
8
5
6
7
D: Align the set-screw
hole of (2) with the D-
shaped cut on (1)
(2)
(1)
C: D-shaped cut
Motor shaft
EJM8A-E-SMA050306-A01-00
Page　5-3-6-3
Machinery Part Replacement
Remarks
L
ight Transfer-Head Assembly (8-nozzle type
)
Item
How to install the motor:
Install the Z-axis motor, positioning the
set-screw hole of D above 90 degrees away
from the mark on the motor shaft.
・Raise the ball screw almost to
maximum.
･The set-screw hole of "D" above should
be positioned more than 90 degrees
away from the mark on the motor. The
hole should be displaced
counterclockwise when seen from above.
Secure the Z-axis motor cables with
cable ties. Nipper
Cable tie 100mm
11
10
9
Mark on "C" should be
more than 90 degrees
away from the set-screw
hole of "D."
Raise it almost to
maximum.
Mark put when "C"
was assembled.
Set-screw hole
Mark put when "C"
was assembled.
Set-screw of "D"
Set-screw of "D"
Mark on "C" should be more than 90
degrees away from the set-screw hole
of "D."
EJM8A-E-SMA050306-A01-00
Page　5-3-6-4
Machinery Part Replacement
Remarks
L
ight Transfer-Head Assembly (8-nozzle type
)
Item
Refer to "Separating the Z-Unit from the
Board."
Section 5-3-14
Put the head assembly back on.
Refer to "Transfer Head Replacement." Section 5-3-1
Switch on the main power and air supply.
Open the cock of the MR unit.
Place the Z-axis controlling board in position.
14
13
12
1
2
EJM8A-E-SMA050306-A01-00
Page　5-3-6-5
