Machinery Part Replacement This section describes the procedures for replacing the clamper hook. ・ Tools None ・ Jig None L ight Transfer-Head Assembly (8-nozzle type ) 5-3-8 Clamp Hook Replacement Caution Dange r Warning…
Machinery Part Replacement
Remarks
L
ight Transfer-Head Assembly (8-nozzle type
)
Item
Nozzle Holder Angle Adjustment
Teaching:
Board Recognition Camera --- X
and Y-axis Origin Offset
Z-axis Origin Offset
Chip Recognition Camera and
Theta-axis Origin Offset
Determining the Mounting Height
and Positionig the Board
Mounting Position
Pickup Position
Nozzle Exchan
g
e Position
Section 4-1-8
Section 4-2-2
Section 4-2-3
Section 4-2-4
Section 4-2-5
Section 4-2-7
Section 4-2-8
Section 4-2-9
13
EJM8A-E-SMA050307-A01-00
Page5-3-7-5
Machinery Part Replacement
This section describes the procedures for replacing the clamper hook.
・Tools
None
・Jig
None
L
ight Transfer-Head Assembly (8-nozzle type
)
5-3-8 Clamp Hook Replacement
Caution
Dange
r
Warning
Assembly
Adjustment
3min.
Teaching
min.
Total Time Weight of
Part
Removal
Disassembly
2min.
5min.
kgs
EJM8A-E-SMA050308-A01-00
Page 5-3-8-1
Machinery Part Replacement
Remarks
Remove the nozzle holder.
Remove the spring.
Apply grease to the holder. Apply a small amount of grease. BARRIERTA IEL
Fit the spring.
Replace the hook.
Be careful with the orientation (upper and
lower sides) of the hook.
Item
2
3
4
1
L
ight Transfer-Head Assembly (8-nozzle type
)
Apply grease here.
EJM8A-E-SMA050308-A01-00
Page 5-3-8-2
