Machinery Part Replacement This section describes the procedures for replacing the vacuum sensor. ・ Tools Precision screwdriver Phillips screwdriver #1 Allen key 2.5 mm Nipper Cable ties ・ Jig None 5-3-10 Vacuum Sensor R…
Machinery Part Replacement
Remarks
Light Transfer-Head Assembly (8-nozzle type)
Item
Lock the new fan.
Be careful with the orientation of the fan. Allen key 2.5 mm
Screw M3 4 pcs.
Connect Connector CN5.
Put back the head cover.
Phillips screwdriver #1
Phillips screwdriver #2
Switch on the main power.
7
8
5
6
CN1
CN2
CN3 CN4
CN5
CN12
CN10CN9
CN7
CN6
MC14CX
EJM8A-E-SMA050309-A01-00
Page 5-3-9-3
Machinery Part Replacement
This section describes the procedures for replacing the vacuum sensor.
・Tools
Precision screwdriver
Phillips screwdriver #1
Allen key 2.5 mm
Nipper
Cable ties
・Jig
None
5-3-10 Vacuum Sensor Replacement
L
ight Transfer-Head Assembly (8-nozzle type
)
Caution
Dange
r
Warning
Assembly
Adjustment
40min.
Teaching
min.
Total Time Weight of
Part
Removal
Disassembly
40min.
80min.
kgs
EJM8A-E-SMA050310-A01-00
Page 5-3-10-1
Machinery Part Replacement
Remarks
Switch off the main power and air supply.
Remove the head assembly.
Refer to "Transfer Head Replacement." Section 5-3-1
Remove the vacuum sensor connector.
Cut the cable ties. Rear side
Nipper
L
ight Transfer-Head Assembly (8-nozzle type
)
Item
1
2
3
4
CN1
CN2
CN3 CN4
CN5
CN12
CN10CN9
CN7
CN6
MC14CX
The same boards are installed at the
front and the rear sides of the head
assembly.
1
2
EJM8A-E-SMA050310-A01-00
Page 5-3-10-2
