CM602all_EJM8AESM_Service Manual - 第491页
This section describes the procedures for replacing the clamp hook. Phillips screwdriver #2 Barrierta IEL None 5-4-4 Clamp Hook Replacement Machinery Part Replacement Light Transfer-Head Assembly (3-nozzle type) • Tools …
See "Head Unit Replacement."
18
Machinery Part Replacement
Section 5-4-2
Allen key 3 mm
Nipper
Screw M4 3 pcs.
Put the head unit back on.
Tool/Spec/Installation
17
Item Remarks
Tool/Spec/Installation
Light Transfer-Head Assembly (3-nozzle type)
Put the top cover back on. Secure the cables.
EJM8A-E-SMA050403-A01-00
Page 5-4-3-6
This section describes the procedures for replacing the clamp hook.
Phillips screwdriver #2
Barrierta IEL
None
5-4-4 Clamp Hook Replacement
Machinery Part Replacement
Light Transfer-Head Assembly (3-nozzle type)
• Tools
• Jigs
Removal/Disassembly
10
Min.
Part Weight
5
Min.
Kg
Assembly/Adjustment
Teaching Total Time
5
Min. Min.
Caution
Danger
Warning
EJM8A-E-SMA050404-A01-00
Page 5-4-4-1
Machinery Part Replacement
Light Transfer-Head Assembly (3-nozzle type)
Tool/Spec/Installation
Tool/Spec/Installation
4
Remarks
Phillips screwdriver #2
Screw M4 2 pcs.
3
Apply grease to the holder.
2
1
Item
Remove the hook from the nozzle clamp.
Remove the feeder cover.
Fit the clamp hook.
Tool/Spec/Installation
Grease
Tool/Spec/Installation
EJM8A-E-SMA050404-A01-00
Page 5-4-4-2
