Switch off the power and air supply. Install the multi-purpose head Remove the high-speed head. 3 BLOCK ： KXFB02KDA00 2 pcs. See Section "5- ３ -1 Transfer Head Assembly Replacement" Remarks 4 2 1 Item Machinery…
180
See each procedures.
Phillips screwdriver #2
Phillips screwdriver #1
Volume adjusting
screwdriver
Allen key 3 mm
Allen key 4 mm
Iron plate
Dial gauge
Magnetic stand
Feeler gauge
kgs
600 min.
Total Time Part Weight
10 max.
Removal/Disassembly
240
Teaching
180 min.
Assembly/Adjustment
Machinery Part Replacement
Z Unit (3-nozzle type)
• This section describes the procedures for changing the high-speed head to the multi-purpose one.
5-5-3 Head Change (High-speed type ⇒ Multi-purpose type)
・Tools
・Jigs
min. min.
Dange
r
Warning
Caution
EJM8A-E-SMA050503-A01-00
Page 5-5-3-1
Switch off the power and air supply.
Install the multi-purpose head
Remove the high-speed head.
3
BLOCK：KXFB02KDA00
2 pcs.
See Section "5-３-1
Transfer Head Assembly
Replacement"
Remarks
4
2
1
Item
Machinery Part Replacement
Z Unit (3-nozzle type)
See Section 5-5-1.
Replacing a Set of Head
Units."
Mount the stopper block.
1
2
High-speed head
Multi-purpose head
EJM8A-E-SMA050503-A01-00
Page 5-5-3-2
interference sensor dog.
Place the lead checker sensor amplifier.
See Section "6-2-5 3-Head
Support Regulator
Replacement."
See Sections "6-3-1.
Installing the Lead
Checker"
Place the electropneumatic regulator.
Do not move the dog.
Feeler gauge
Remarks
6
7
Adjust the collision preventing photo sensor so that it turns ON when the gap of
the collision preventing stopper and the X beam is 0.5 mm.
5
Move it up to the other end of the cut.
Item
Precisely position the Y-axis
8
Machinery Part Replacement
Z Unit (3-nozzle type)
[Multi-purpose head][High-speed head]
0.5
Dog
0.5
High-speed head
Multi-purpose head
Collision preventing
stopper
PH bracketDog
Collision preventing
stopper
PH bracket
EJM8A-E-SMA050503-A01-00
Page 5-5-3-3
