CM602all_EJM8AESM_Service Manual - 第509页

Change the system parameters. Change the setup of the desired stag e Change the system parameters to "Multi head." Check the basic parameters. Check the optional parameters. according to the machine specificati…

100%1 / 1093
Place the multi-purpose nozzle changer.
Remove the high-speed nozzle changer.
Z Unit (3-nozzle type)
Remarks
Place the laser board.
See Section "6-1-3
Nozzle Changer
Replacement (High-Speed
Machines)."
See Sections "6-3-1.
Adding a Lead Checker"
10
11
9
Machinery Part Replacement
Item
Connect the connectors.
12
See Section "6-2-3.
Nozzle Changer
Replacement (Multi-
Purpose Machines)."
Amplifier
Sensor
CPUBO
X
Multi-purpose head
High-speed head
EJM8A-E-SMA050503-A01-00
Page　5-5-3-4
Change the system parameters.
Change the setup of the desired stag
e
Change the system parameters
to "Multi head."
Check the basic parameters. Check the optional parameters.
according to the machine specifications.
16
15
14
13
Switch on the power and air supply
.
From 0.49 Pa
To 0.54MPa
Item Remarks
Machinery Part Replacement
Z Unit (3-nozzle type)
1
2
EJM8A-E-SMA050503-A01-00
Page　5-5-3-5
Check machine parameters.
Correct the old offsets.
After changing the head, enter Z=+2.
Offset range:
1.0 to 11.0
If an value exceeding the range
is entered, an axis error will occur.
4-1-2: Head Camera Adjustment
Check the previous and the next
processes
.
Once system parameters
have been changed, power
down and then power up
the machine.
Item Remarks
18
The other adjustments:
Teaching:
17
20
19
Correct Z-axis offset positions 1 to 3.
Z=+2
Enter +2, when changing
the head no matter which
way from the high-speed
to the multi-purpose type
or from the multi-purpose
to the high-speed type.
--- Focus and Thet
a
4-3-2: Board Recognition Camera --- X and Y-axis Origin Offset
4-3-3: Z-axis Origin Offset
4-3-4: Chip Recognition Camera --- Theta Axis Origin Offset
4-3-5: Determining the Mounting Height and Positioning the Board
4-3-6: XY Plane Calibration
4-3-8: Pickup Position
4-3-9: Nozzle Exchange Position
4-3-10: Load Head
4-3-11: Lead Checker
4-3-12: Light Intensity
4-3-7: Mounting Position
Machinery Part Replacement
Z Unit (3-nozzle type)
EJM8A-E-SMA050503-A01-00
Page　5-5-3-6
