Top view Take care with the orientation of the Connect the connector. Tools and Specifications 8 7 6 5 Fit the LED lamp into the new camera. Tools and Specifications Allen key 3 mm Screw M4 4 pcs. Tools and Specification…
Be careful not to let the camera fall.
Phillips screwdriver #1
Phillips screwdriver #2
Screw M3 8 pcs.
M4 4 pcs.
Tools and Specifications
Head Camera Unit
Item Remarks
Tools and Specifications
Switch off the main power.
3
Allen key 3 mm
Screw M4 4 pcs.
Phillips screwdriver #1
Connector screw
4
2
1
Machinery Part Replacement
Remove the head cover
.
Tools and Specifications
Disconnect the connector.
Tools and Specifications
Remove the camera holding screws, holding the camera.
EJM8A-E-SMA050602-A01-00
Page 5-6-2-2
Top view
Take care with the orientation of the
Connect the connector.
Tools and Specifications
8
7
6
5
Fit the LED lamp into the new camera.
Tools and Specifications
Allen key 3 mm
Screw M4 4 pcs.
Tools and Specifications
connector.
Install the camera. Lightly tighten the screws so that the camera will not fall.
Tools and Specifications
Allen key 3 mm
Screw M4 4 pcs.
Remove the LED lamp from the camera.
Machinery Part Replacement Head Camera Unit
Item Remarks
Camera connector
LED cable
Take care with the orientation of the
camera. (Check the connector position.)
EJM8A-E-SMA050602-A01-00
Page 5-6-2-3
Refer to "Head Camera Adjustment
--- Focus and Theta --."
Adjust the camera.
10
11
Put the head cover back on.
Phillips screwdriver #1
Phillips screwdriver #2
Screw M3 8 pcs.
M4 4 pcs.
Section 4-1-2
Tools and Specifications
Tools and Specifications
9
Switch on the main power.
Item Remarks
Machinery Part Replacement Head Camera Unit
Tools and Specifications
EJM8A-E-SMA050602-A01-00
Page 5-6-2-4
