Kgs. Weight o f Part 20 min. 47 min. min. 67 min. Removal Disassembly A ssembly Adjustment Teaching Total Time ・ Tools 5-6-3 Head-Camera LED Light Replacement Machinery Part Replacement Head Camera Unit This section desc…
Refer to "Head Camera Adjustment
--- Focus and Theta --."
Adjust the camera.
10
11
Put the head cover back on.
Phillips screwdriver #1
Phillips screwdriver #2
Screw M3 8 pcs.
M4 4 pcs.
Section 4-1-2
Tools and Specifications
Tools and Specifications
9
Switch on the main power.
Item Remarks
Machinery Part Replacement Head Camera Unit
Tools and Specifications
EJM8A-E-SMA050602-A01-00
Page 5-6-2-4
Kgs.
Weight o
f
Part
20 min. 47 min. min.
67
min.
Removal
Disassembly
A
ssembly
Adjustment
Teaching Total Time
・Tools
5-6-3 Head-Camera LED Light Replacement
Machinery Part Replacement Head Camera Unit
This section describes the procedures for replacing the head LED light.
Phillips screwdriver #1
Phillips screwdriver #2
Allen key 3 mm
FM-1112
Head Camera Height Jig
・Jig
Dange
r
Warning
Caution
EJM8A-E-SMA050603-A01-00
Page 5-6-3-1
Be careful not to let the camera fall.
Tools and Specifications
Remove the camera holding screws, holding the camera.
2
1
4
3
Item Remarks
Allen key 3 mm
Screw M4 4 pcs.
Remove the head cover.
Switch off the main power.
Tools and Specifications
Tools and Specifications
Phillips screwdriver #1
Connector screw
Disconnect the connector.
Tools and Specifications
Phillips screwdriver #1
Phillips screwdriver #2
Screw M3 8 pcs.
M4 4 pcs.
Machinery Part Replacement Head Camera Unit
EJM8A-E-SMA050603-A01-00
Page 5-6-3-2
