5-8-2 Feeder-Cart-Unit Replacement and Adjustment • This section describes the procedures for replacing and adjusting the feeder exchange cart unit. 20 Feeder exchange cart unit adjustment jig Teaching Removal/Disassembl…
Machinery Part Replacement
Remarks
Feeder Gang Exchange Cart Holding Section
Item
Close the top cover.
21
EJM8A-E-SMA050801-A01-00
Page5-8-1-7
5-8-2 Feeder-Cart-Unit Replacement and Adjustment
• This section describes the procedures for replacing and adjusting the feeder exchange cart unit.
20
Feeder exchange cart unit
adjustment jig
Teaching
Removal/Disassembly
Min.
Machinery Part Replacement Feeder Cart Installing Section
Part Weight
Assembly/Adjustment
60
Min.
40
Total
kgs.
・Jigs
・Tools
Phillips screwdriver #2
Allen keys 2.5mm to 6mm
Magnetic stand holding
iron plate
Magnetic stand
Dial gauge
Min.Min.
Dange
r
Warning
Caution
EJM8A-E-SMA050802-A01-00
Page 5-8-2-1
3
4
Remove the chute.
Remove the feeder cover bracket.
2
1
Remarks
Machinery Part Replacement Feeder Cart Installing Section
Switch off the power.
Remove the feeder cover.
Allen key 3 mm
Screw M4 x 10mm 3 pcs.
Thick washer 3 pcs.
Item
Phillips screwdriver #2
Screw M4 2 pcs.
Remove the left
and the right
screws. Raise
the feeder cover.
EJM8A-E-SMA050802-A01-00
Page 5-8-2-2
