Machinery Part Replacement
This section describes the procedures for removing the clamp arm.
Tools
None
Jig
None
12-Nozzle Head Unit
　　5-10-10　　　　 Clamp Arm Replacement
Caution
Dange
r
Warning
EJM8A-E-SMA051010-A01-00
Page　5-10-10-1
Machinery Part Replacement
Remark
Remove the nozzle holder.
Remove the spring and apply grease to it.
Barrierta IEL
Fit the spring.
12-Nozzle Head Unit
3
1
Item
2
A
1
A: Grease position
(Same to opposite side)
* Groove with which the
clam
p
arm makes contact.
Ref. Finished image
One side of c and the
hook of the d should be
positioned on the same
side.
d
c
Narrow
Wide
Open side
Open side
Open side
Open side
Position the hooks so that the two
"open sides" should not face in the
same direction when the spring is fit.
cGrease position
EJM8A-E-SMA051010-A01-00
Page　5-10-10-2
Machinery Part Replacement
Remark
12-Nozzle Head Unit
Item
Replace the arm.
Be careful not to position the arm upside
down.
Fit the spring and the nozzle holder
5
4
Narrow
Wide
EJM8A-E-SMA051010-A01-00
Page　5-10-10-3
