The levels at left shows the relationshi p between ( 1 ) and ( 3 ) or ( 2 ) and ( 4 ) above: the range of 900 to 920 mm. Leave the center adjusting bolt raised. Tools and Specification lock the adjusting bolts. Wrench 45…

100%1 / 1093
Reference of Levelness Jud
g
ment
When the reading remains
same after the level is
rotated, the level has been
leveled.
Proceed to levelness of the
machine.
4-5
4-6
Machine Setting
Item Remarks
Check after the level is leveled.
Setting
60
9
245
1
Operator's
side
60
43
9
245
9
245
77
9
245
36
36
77
2
3
4
5
60
43
6
EJM8A-E-SMA020102-A01-00
Page 2-1-2-4
The levels at left shows
the relationshi
p
between
(
1
)
and
(
3
)
or
(
2
)
and
(
4
)
above:
the range of 900 to 920 mm.
Leave the center adjusting bolt raised.
Tools and Specification
lock the adjusting bolts.
Wrench 45 mm 2 pcs.
When the reading s of levels (1) and (3),
and (2) and (4) are matched with one of
the examples A, B and C, the machine is
leveled.
[Specifications]
The levels of each position should be
symmetrical. Difference should be 0.04
mm/m or less. (1 div. should be 0/02
mm/m)
When the readings of levels (1) and (3), and
(2) and (4) are not symmetrical as shown in
the examples D, E, and F, the machine is not
leveled correctly.
Even when the bubble of one of the levels is
positioned in the center, the levelness is not
acceptable.
[Specifications]
The levels of each position should be
symmetrical. Difference should be 0.04 mm/m
or less. (1 div. should be 0.02 mm/m)
4-7)
Levelness: Good Levelness: NG
5
Adjust Adjusting Bolts A, C, D and F
Checking the height of the transfer
Tools and Specification
checking Levels 1, 2, 3, 4, 5 and 6.
conveyor belt, adjust the height to
Level
Wrench 45 mm
Spec.: 0.04 mm or less
6
Once adjustment has been complete,
Item
Setting Machine Setting
Remarks
Ａ ＧＢ Ｃ Ｄ Ｅ Ｆ
Center line
EJM8A-E-SMA020102-A01-00
Page 2-1-2-5
Lower the Adjusting Bolts B and E to the
floor so that the feet of the bolts do not
move. Rotate the bolts 45 degrees and
lock the lock nuts.
Once adjustment has been complete, lock the adjusting bolts.
Put a mark on the lock nut. Check that the bolt is seated securely.
7
Lower the center adjusting bolt to the floor
Tools and Specification
Check the levelness.
Level
Wrench 45 mm
Spec.: 0.04 mm or less
45°
9
8
Wrench 45 mm 2 pcs.
Setting Machine Setting
Item Remarks
(1)
(3)
(2)
(4)
(5)
(6)
EJM8A-E-SMA020102-A01-00
