Conveyor ref. side ... Board stopper side ... Movable conveyor ... side • Put one sheet of paper (plain paper) on the light box. (To reduce light intensity) • Put the light box on the stage to teach. • Shadow recognition…
should be positioned on the reference side.
Prepare the stage to teach as shown below.
• Turn on the power switch of the light box. (Do not connect the plug yet.)
• The narrow side between the end and the lighting portion of the box
RemarksItem
1
Load the data.
Direct recognition: [TdEJM4A-a2-DIR0]
Adjust the width of the conveyors.
Shadow recognition: [TdEJM4A-a2-SHA0]
Put the pins on the pin plate. Put the light box in the machine.
Select the teaching data and press [Load].
* To avoid pin interference, check there are no pins on the plate beforehand.
2
3
4
Machinery Part Replacement 12-Nozzle Head Teaching
Light box
Press [File management].
Press [Floppy disk].
Press [Machine adjust]. Press [Cnvr adjustment]. Press [Prd data PCB w].
Press [Run].
Plug
Support
block
(
Left
)
Support
block (Right)
Light box
Ref.
id
Stopper side
Narrow side
Pin position
Truss screw
EJM8A-E-SMA051111-A01-00
Page 5-11-11-2
Conveyor ref. side ...
Board stopper side ...
Movable conveyor ...
side
• Put one sheet of paper (plain paper) on the light box.
(To reduce light intensity)
• Put the light box on the stage to teach.
• Shadow recognition teaching: 110S
• Direct recognition teaching: 205S
• Shadow recognition teaching: Feeder change cart
Work: 1005R
Work-setting position: Left of the tape feeder
• Direct recognition teaching:
Work: 0603R
Work-settin
g
position: Ri
g
ht of the tape feeder
Tape feeder
Press [Production data teach].
Press [Pick pos learning].
Select the stage.
Remarks
5
Put the light box in the machine.
to the stopper. (Same pitch: Visual check)
Three pins: Press the light box against the above-
Machinery Part Replacement 12-Nozzle Head Teaching
• Put pins on the following positions, and put the light box in the machine.
mentioned pins and position pins along the box.
Three pins: One for next to each truss screw
(Opposite side of each truss screw to the stopper.)
Two pins: Vertical side of the plate corner close
Put an 8-mm-wide tape feeder on the number 7 position of each feeder change cart
.
(12 nozzles for each head, 48 for all stages)
7
8
Adjust the pickup position.
Press [Data modify].
6
Item
Fit the nozzles on all the nozzle holders for a head.
To Step 9
EJM8A-E-SMA051111-A01-00
Page 5-11-11-3
Press [Complete].
Press [Performance info]. Press [Reset]. Press [Run].
Press [Yes].
Press [Performance info]. Press [Pick Info]. Press [Error scrn].
Press [Reset].
RemarksItem
12-Nozzle Head Teaching
Press [Next pick posi].
P
ress [RecogReflect]
10
Machinery Part Replacement
9
12
Reset the recognition-error screen.
Reset the production data.
11
From Step 8
Press [Tape feed] to feed a
component to the pickup
position.
Ta
p
e
p
ocke
t
Component
Check the tape pocket is
p
ositioned in the center.
Repeat all the above steps for
each stage.
Mount-position-teaching jig
240 x 216 glass board
EJM8A-E-SMA051111-A01-00
Page 5-11-11-4
