Optional Accessory Parts Replacement Remarks Nozzle Changer Unit (8-nozzle type) Item Teaching Nozzle Change Position See Section 4-3-9. Teaching jig (FM-0655) 17 EJM8A-E-SMA060103-A01-00 Page6-1-3-6

100%1 / 1093
Optional Accessory Parts Replacement
Remarks
Nozzle Changer Unit (8-nozzle type)
Item
Nipper
Cable tie 150 mm
5 pcs.
Put the side cover back on.
Phillips screwdriver #2
Truss screw M4 4 pcs.
Phillips screwdriver #2
Allen key 3 mm
Screw M4 2 pcs.
Screw M4 x 10mm 3 pcs.
Thick washer 3 pcs.
Switch on the main power.
Turn the switch right.
Put the feeder cover and the chute back on.
Secure the cables, aligning them with other cables.
14
15
16
13
EJM8A-E-SMA060103-A01-00
Page6-1-3-5
Optional Accessory Parts Replacement
Remarks
Nozzle Changer Unit (8-nozzle type)
Item
Teaching
Nozzle Change Position See Section 4-3-9.
Teaching jig (FM-0655)
17
EJM8A-E-SMA060103-A01-00
Page6-1-3-6
Total　Time
Weight of
Par
t
20 min. min.
min
.
Kgs.
min.
Removal
Disassembly
A
ssembl
y
Adjustment
Teaching
6-1-4 Slide Cover Replacement (High-Speed Machines)
• Tools
This section describes the procedures for replacing the slide cover for high-speed machines.
Phillips screwdriver #2
Allen key 2.5 mm
Calipers
• Jigs
20
Optional Accessory Parts Replacement Nozzle Changer Unit (8-nozzle type)
40
None
Caution
Danger
Warning
EJM8A-E-SMA060104-A01-00
Page　6-1-4-1
