CM602all_EJM8AESM_Service Manual - 第75页

[Tool] Tester Precision screwdriver [Specifications] 24.00 to 24.30V [Tools] Tester Precision screwdriver [Specifications] 24.00 to 24.30V Item Remark Insert the tester rod into the hole s 21 circled below: 24 24V-2 Meas…

100%1 / 1093
[Tool]
Tester
Precision screwdriver
[Specifications]
　12.60 to 13.00V
[Tool]
Tester
Precision screwdriver
[Specifications]
　12.60 to 13.00V
20
Measure DC voltage P12V-2
12V-2
Adjust the voltage with the electric source in the Stage A box.
* Skip this item if not necessary.
Installation Machine Installation
circled below:
19
12V-2
18
Measure DC voltage　P12V-1
12V-1
Measure DC voltage　P12V-1, P12V-2
Insert the tester rod into the hole
s
Adjust the voltage with the electric source in the Stage B box.
* Skip this item if not necessary.
Remark
17
24V-1
circled below:
Measure DC voltage　P24V-1, P24V-2
Insert the tester rod into the hole
s
Item
P24V-1　Red
GND　Black
Tester　DC20V　range
P12V-2　Red
GND　Black
Tester　DC20V　range
EJM8A-E-SMA020103-A01-00 Page　2-1-3-6
[Tool]
Tester
Precision screwdriver
[Specifications]
　24.00 to 24.30V
[Tools]
Tester
Precision screwdriver
[Specifications]
　24.00 to 24.30V
Item Remark
Insert the tester rod into the hole
s
21
circled below:
24
24V-2
Measure DC voltage.　P24V-1, P24V-2 Adjust the voltage with the electric source in the Stage A box.
* Skip this item if not necessary.
22
23
24V-2 circled below:
Measure DC voltage　P24V-1, P24V-2
Insert the tester rod into the holes
Adjust the voltage with the electric source in the Stage B box.
* Skip this item if not necessary.
Installation Machine Installation
Measure DC voltage　P24V-1, P24V-2
24V-1
Measure DC voltage　P24V-1, P24V-2
24V-1
P24V-1　Red
GND　Black
Tester　DC20V　range
P24V-2　Red
GND　Black
Tester　DC20V　range
EJM8A-E-SMA020103-A01-00 Page　2-1-3-7
[Tools]
Tester
[Specifications]
　12.02V to 12.10V
[Tools]
Tester
[Specifications]
　12.02V to 12.10V
27
Check the direction of vacuum pump
rotation. (High-speed) Check vacuum.
Select (1) "Machine adjust" and (2) "Output check."
"Output check" window
28
(1) "UNLOCK" (2) " Vacuum pump" (3) "Vacuum"
Check the direction of vacuum pump Turn on the vacuum pump.
26
Color touch panel electric source RF-IP(Front)
Measure 12V.
Measure it, placing the tester rod on the
12V output terminal.
* If the value is outside the spec., adjust
the voltage with the volume so that it
satisfies the spec.
25
Measure 12V.
Color touch panel electric source RF-IP(Front)
Measure it, placing the tester rod on the
12V output terminal.
* If the value is outside the spec., adjust
the voltage with the volume so that it
satisfies the spec.
Installation Machine Installation
Item Remark
(1)
(2)
(1)
(2)
(3)
12V　Red
GND　Black
Tester　DC20V　range
12V　Red
GND　Black
Tester　DC20V　range
EJM8A-E-SMA020103-A01-00 Page　2-1-3-8
