See Section 4-3-9 "Nozzle Exchange Position" Remark Nozzle Changer Unit (3-nozzle type) Optional Part and Accessory Replacement 13 Switch ON the main power and Tool/Spec./Installation air supply. 16 Teaching To…
Nozzle Changer Unit (3-nozzle type)Optional Part and Accessory Replacement
Item Remark
9
Adjust the nozzle changer so that
Tool/Spec./Installation
it is parallel.
Specifications:
Parallelism:
0.02 mm or less
Tool/Spec./Installation
Phillips screwdriver #2
Screw M4 4 pcs.
Tool/Spec./Installation
connectors.
Put the right side cover back on.
Tool/Spec./Installation
11
Connect the nozzle changer
10
Connect the cylinder air hose.
12
EJM8A-E-SMA060203-A01-00
Page 6-2-3-4
See Section 4-3-9 "Nozzle Exchange Position"
Remark
Nozzle Changer Unit (3-nozzle type)Optional Part and Accessory Replacement
13
Switch ON the main power and
Tool/Spec./Installation
air supply.
16
Teaching
Tool/Spec./Installation
See Section 4-3-9.
Phillips screwdriver #2
Allen key 3 mm
Screw M4 2 pcs.
Screw M4 3 pcs.
14
15
Put the chute and the feeder cover
back on.
Adjust the stroke of the nozzle changer shutter with the adjuster placed on
the cylinder section.
Caliper
Shutter: Open:
A=15.75±0.25 mm
B=0±0.25 mm
Shutter: Closed
A=0±0.25 mm
B=15.75±0.25 mm
Tool/Spec./Installation
Item
1
2
B
A
EJM8A-E-SMA060203-A01-00
Page 6-2-3-5
6-2-4 Slide Cover Replacement (Multi-Purpose Machines)
Optional Accessory Parts Replacement Nozzle Changer Unit (3-nozzle type)
This section describes the procedures for replacing the slide cover for multi-purpose machines.
Removal
Disassembl
y
A
ssembl
y
A
d
j
ustmen
t
Kgs.
min.
15
min.
Teaching
Phillips screwdriver #2
Flat-head screwdriver #2
Allen key 2.5 mm
Wrench 13 mm
Calipers
10 min.
• Tools
• Jigs
5 min.
Total Time
None
Weigh
t
o
f
Part
Caution
Danger
Warning
EJM8A-E-SMA060204-A01-00
Page 6-2-4-1
