Optional Accessory Parts Replacement Lead Checker 21 Install the amplifier in the center. Item Remark 20 Put Bracket (5) on the rear side of Amplifier (7). Allen key 3 mm Screw M4 4 pcs. Allen key 3 mm Screw M4 1 pc. Iro…

100%1 / 1093
18
16
Set up the DIP switches, which are
Allen key 3 mm
Screw M4 2 pcs.
located at the rear side of the amplifier.
Fit Bracket ⑥.
Fix the amplifier in place.
Insert the amplifier.
Phillips screwdriver #2
Terminal screw 3 pcs.
17
Optional Accessory Parts Replacement Lead Checker
Item Remark
Connect the amplifier power cable.
Connect the communication cables.
Open the left covers on the AF, AR
Amplifier holding bracket
(small)
Allen key 3 mm
Screw M4 2 pcs.
19
and BR stages.
C
D
Sensor
cable
A
12 3 4
ON
6
EJM8A-E-SMA060301-A01-00
Page　6-3-1-8
Optional Accessory Parts Replacement Lead Checker
21
Install the amplifier in the center.
Item Remark
20
Put Bracket (5) on the rear side of
Amplifier (7).
Allen key 3 mm
Screw M4 4 pcs.
Allen key 3 mm
Screw M4 1 pc.
Iron plate for holding the
magnetic stand
Place the iron plate on the head so that
the magnetic stand can be placed on the plate.
Bracket (3).
Specifications:
Parallelism:
0.02 mm or less
Allen key 3 mm
Allen key 4 mm
Screw M4 2 pcs.
Screw M5 2 pcs.
Magnetic stand
Dial gauge
Adjust the bracket so that it is parallel
to the Y-axis. Fix the bracket in place.
23
Lightly tighten Sensor Holding
22
Open the left cover on the BF stage.
Allen key 3 mm
Screw M4 2 pcs.
EJM8A-E-SMA060301-A01-00
Page　6-3-1-9
Lead Checker
to the top of the sensor.
Specifications:
H: 174mm±0.2mm
Allen key 3 mm
Screw M4 2 pcs.
24
Item
Phillips screwdriver #2
Truss screw 6 mm
4 pcs.
(3 pcs. for AF only)
Remark
Optional Accessory Parts Replacement
Lightly tighten Sensor (4). Adjust the height from the body frame
Put the lower box cover back on.
Put all lower chutes back on.
27
Switch on the power.
25
26
Allen key 4 mm
Screw M5 x 12 mm
4 pcs.
Thick washer 43 pcs.
H
Chute holding
section (Left)
Chute holding
section (Right)
EJM8A-E-SMA060301-A01-00
Page　6-3-1-10
