6 Option Accessory Parts

Replacement

(Component Height Control Device)

This chapter describes the procedures for replacing the

optional accessory parts.

EJM8A-E-SMAA-0002

Confidential

Additional version

• Tools

Phillips screwdriver #1

Phillips screwdriver #2

Allen key 5 mm

Pipe

Nippers

Non-magnetic Allen key

• Jigs

Covers (large) (Small)

Component-height-

detection-sensor-

adjusitng power source

<FM-1853(1)>

Preparation: Remove all the nozzles and nozzle holders from the head.

[Caution before replacement] * Since there are magnets, great care must be taken

to ensure safety when working on the machine.

Component-Thickness-Measuring Unit

6-4-1 Component-Thickness-Sensor-Amplifier Replacement (12-Nozzle-Head Spec.)

Option Part and Accessory Replacement

This section describes the procedures for replacing the component-thickness-sensor amplifier

(12-nozzle-head specifications).

　　　　　Component-Thickness-Measuring Unit

6-4

Dange

Warning

Caution

EJM8A-E-SMA060401-A01-01

Page　6-4-1-1
