Remark
Item
Component-Thickness-Measuring Unit
Option Part and Accessory Replacement
O
p
en the am
p
lifier cover.
Check the am
p
lifier is
p
owered u
p
.
Switch on the component-thickness-sensor-adjusting jig.
24
25
26
Open the amplifier cover.
Switch on the component-height-
detection-sensor-adjusting power source.
* The jig should be plugged in.
Check the amplifier is powered up.
EJM8A-E-SMA060401-A01-01
Page　6-4-1-8
Remark
Item
Component-Thickness-Measuring Unit
Option Part and Accessory Replacement
A
mplifier setting
Settin
g
of nozzle front line
(
1 to 6
)
CN40
27
28
29
Hold down the Mode
button for a few
seconds.
When "L-on" is displayed,
press the Manual button to
change the display to "d-on."
* Press either side of the button.
Check "d-on" and press
the Mode button.
* Do not hold it down for
a long time.
When "FinE" is displayed,
press the Manual button
to change the display to
"hsp."
To the next page
Mode button
A
dd-in
p
rotection cover
C
hannel switch
(
dis
p
la
y
settin
g)
Manual button
Dust cover
A
dd-in connector
Di
g
ital monitor
Set button
Hold lock
bar
Out
p
ut indicator
(
Control out
p
ut 2
)
Out
p
ut indicator
(
Control out
p
ut 1
)
EJM8A-E-SMA060401-A01-01
Page　6-4-1-9
Remark
Item
Component-Thickness-Measuring Unit
Option Part and Accessory Replacement
Out
p
ut-2 threshold settin
g
Press the "Manual" button until the value
becomes 2000.
32
30
31
33
Check "hsp"and press
the Mode button.
* Do not hold it down for
a long time.
Check "End"and press
the Mode button.
* Do not hold it down for
a long time.
"End" is displayed and the
original display is returned.
Hold down the
"←" of the
Manual
button
until
1250
Check "1250" and
change the channel
switch from 1 to 2.
End of
amplifier setting
From the previous page
Threshold
EJM8A-E-SMA060401-A01-01
Page　6-4-1-10
