Remark Item Component-Thickness-Measuring Unit Option Part and Accessory Replacement Put the upper head cover back on. Phillips screwdriver #2 Truss M4 4 pcs. * Since there are magnets, ensure safety using a non-magnetic…

100%1 / 1093
Remark
Item
Component-Thickness-Measuring Unit
Option Part and Accessory Replacement
Fit the am
p
lifier-holdin
g
bolt.
(
2
)
Fit the am
p
lifier-holdin
g
bolt.
(
3
)
Phillips screwdriver #2
Screw M4
Insert the CNs39 and 40. Secure the cables with cable ties.
41
42
43
Press the other end of
the bracket against the
cables to lock that end.
Move the bracket in
the ↓ direction.
Pressing the bracket in the
↓ direction and against the
amplifier, tighten the bolt.
Securing cable ties
CN39 and 40
EJM8A-E-SMA060401-A01-01
Page　6-4-1-13
Remark
Item
Component-Thickness-Measuring Unit
Option Part and Accessory Replacement
Put the upper head cover back on.
Phillips screwdriver #2
Truss M4 4 pcs.
* Since there are magnets, ensure
safety using a non-magnetic Allen
keys when working on the machine.
Bolts that come with the
cover (Large): 4 pcs.
Bolts that come with the
cover (Small): 2 pcs.
* Non-magnetic Allen key
Put the feeder cover back on.
Allen key 3 mm
Screw M4 4 pcs.
Turn on the
p
ower and air su
pp
l
y
.
Remove the covers (Large)(Small) from the secondary part.
46
47
44
45
1
2
Bolts
(Large)
Cover (Small)
EJM8A-E-SMA060401-A01-01
Page　6-4-1-14
Remark
Item
Component-Thickness-Measuring Unit
Option Part and Accessory Replacement
A
d
j
ustment
Procedures of Machine parameter
teaching
Z-axis origin offset Service manual 6-4-3
48
EJM8A-E-SMA060401-A01-01
Page　6-4-1-15
