. Check that a warning message and an error message appear when either of the emergency stop switch is pressed. . This warning window appears when the machine is attempted to be operated with the emergency stop switch pr…
■ Check that the machine cover is not
damaged when transferred.
■ If the linear-rails, the ball screw, and
other parts are rusted, remove rust.
■If there are cracks on the cover,
paint it.
■Wipe out rust-preventive and grease
which were applied before delivery.
Remove oil grease
.
Remove oil grease
.
X-side level gauge mounting sectio
n
Y-side level gauge mounting sectio
n
36
Remove oil grease
.
When the machine is operated: 0.50MPa to 0.55MPa
Check reading of the air pressure switc
h
[Targeted value]
Normal machine operation:
0.50MPa to 0.55 Mpa
* Air pressure changes,
depending on environment.
Adjust it, checking
operation condition.
Check air pressure
33
Installation
Item
Remove oil grease
.
35
34
High-speed nozzle change Multi-purpose nozzle change
Machine Installation
Remark
Rust is made: Check there is no damag
e
Remove oil grease from the clam
p
on appearance
.
section of each stage
.
EJM8A-E-SMA020103-A01-00 Page 2-1-3-10
. Check that a warning message and
an error message appear when either
of the emergency stop switch is
pressed.
. This warning window appears when the
machine is attempted to be operated
with the emergency stop switch pressed.
. An error occurs when the emergency
stop switch is pressed during machine
operation (Power ON).
. To reset the switch, pull it.
. Turn off the servo switch.
Operate the machine. (auto run)
Check that the error message
appears.
40
one for each side, front and rear.
39
"Emergency Stop Error" windo
w
"Emergency Stop Error" windo
w
Check the servo switches.
Installation Machine Installation
Item Remark
37
Check the emergency stop switches:
one for each side, front and rear.
38
"Emergency Stop Warning" window
EJM8A-E-SMA020103-A01-00 Page 2-1-3-11
. Check that a warning window appears
when the machine is operated (auto
run) with the cover open.
Installation Machine Installation
Item Remark
41
"Servo Switch Warning" window
42
Check the machine cover switches.
2 for each side: front and rear
43
"Cover Switch Warning" window
44
Check the tape float sensor detection. (4 pcs.)
Check, cutting off the light beam with
* Use "Machine adjust" "Input check. paper or an equivalent tool
EJM8A-E-SMA020103-A01-00 Page 2-1-3-12
