Remark Component-Thickness-Measuring Unit Option Part and Accessory Replacement Item Put the covers ( Lar g e ) ( Small ) on the 5 secondary part. * There are magnets. To ensure safety, use the covers when working on the…
Remark
Remove all the nozzles from the head.
* When removing a nozzle, the ball
spline shaft may be curved. Use the
nozzle changer when removing a
nozzle.
When a nozzle changer is not
mounted, hold the black holder by
hand lightly (so as not to let the axis
descend), and pull the nozzle down
straight. If removing a nozzle without
holding the black holder, a Z-axis-
motor-overload error can occur.
* See Operation manual
5-5-2.
Turn off the air and power supply.
Remove the feeder cover.
3
Allen key 3 mm
Screw M4 4 pcs.
Move the beam whose head will be replaced towards you.
Component-Thickness-Measuring Unit
Option Part and Accessory Replacement
Item
1
2
4
1
2
Rear
Front
EJM8A-E-SMA060402-A01-01
Page 6-4-2-2
Remark
Component-Thickness-Measuring Unit
Option Part and Accessory Replacement
Item
Put the covers
(
Lar
g
e
)
(
Small
)
on the
5
secondary part. * There are magnets. To ensure safety,
use the covers when working on the
machine.
Bolts that come with the
cover (Large): 4 pcs.
Bolts that come with the
cover (Small): 2 pcs.
* Non-magnetic Allen key
Put bubble wra
p
on the line sensor
To avoid losing bolts and the other parts
when they fall down accidentally.
Bubble wrap
7
Phillips screwdriver #2
Truss screw M4 10 pcs.
Remove the cover.
Remove the two "M2.6 x 4L" bolts from
each side: front and rear.
Phillips screwdriver #1
8
6
Remove the head cover and the upper cover.
M2.6 x 4L
(Two for each side: Front and Rear)
Bolts
Cover (Small)
(Large)
EJM8A-E-SMA060402-A01-01
Page 6-4-2-3
Remark
Component-Thickness-Measuring Unit
Option Part and Accessory Replacement
Item
Cut off the sensor-cable-holdin
g
cable
Nippers
10
Nippers
Nippers
9
11
Cut off the sensor-cable-holding cable ties.
Cut off the sensor-cable-holding cable ties.
Holding cable ties
Holding cable ties
Holding cable ties
EJM8A-E-SMA060402-A01-01
Page 6-4-2-4
