Remark Component-Thickness-Measuring Unit Option Part and Accessory Replacement Item Connect CNs 39 and 40. 58 61 Secure the sensor cables with a cable tie. Secure the sensor cables with cable ties. 60 Secure the sensor …
Remark
Component-Thickness-Measuring Unit
Option Part and Accessory Replacement
Item
Put the am
p
lifier on the bracket.
54
Move the amplifier in the (1) and (2)
directions below, and fit the amplifier.
Pre
p
are the holdin
g
bolt.
55
Fit the am
p
lifier-holdin
g
bolt. -
(
1
)
56
Fit the am
p
lifier-holdin
g
bolt. -
(
2
)
57
Phillips screwdriver #2
Screw M4
2
1
Press the bolt end of the bracket
against the cables to lock that end.
Pressing the bracket in the
↓ direction and against the
amplifier, tighten the bolt.
This hook can
move.
Loosen the holding bolt until the end
of it does not come out to the
rear side of the bracket.
EJM8A-E-SMA060402-A01-01
Page 6-4-2-16
Remark
Component-Thickness-Measuring Unit
Option Part and Accessory Replacement
Item
Connect CNs 39 and 40.
58
61
Secure the sensor cables with a cable tie.
Secure the sensor cables with cable ties.
60
Secure the sensor cables with cable ties.
59
Holding cable tie
Holding cable ties
Connect CNs 39 and 40.
Holding cable ties
EJM8A-E-SMA060402-A01-01
Page 6-4-2-17
Remark
Component-Thickness-Measuring Unit
Option Part and Accessory Replacement
Item
Put the cover back on.
63
Install the cover with two "M2.6 x 4L"
bolts for each: front and rear.
Phillips screwdriver #1
64
Phillips screwdriver #2
Truss screw M4 10 pcs.
Secure the sensor cables with cable ties.
62
Put the head cover and the upper cover back on.
Holding cable ties
A
lign the edges of (1) with
that of A or B, and fix the
cover.
There should be no gap
between (1) and A or B.
EJM8A-E-SMA060402-A01-01
Page 6-4-2-18
