Remark Select [Machine parameter] from the main menu. • The machine-parameter menu screen is displayed. Press [Mach prmtr teach]. The "Machine parameter teaching" screen is displayed. 2 3 (A) When Nozzles 130S …

100%1 / 1093
• Tools
• Jigs
• This section describes the procedures for teaching after component-thickness-sensor reaplacement.
(12-nozzle head)
Option Part and Accessory Replacement
Component-Thickness-Measuring Unit
6-4-3 Machine Parameter Teaching Procedures (Z-axis origin offset)
* Before teaching, check no polarizing plates are attached to the head camera.
(5-11-6 Determining the Mounting Height and Positioning the Board, 5-11-7 XY Plane
Calibration, 5-11-8 Pickup Position and 5-11-10 Nozzle Exchange Position)
Notice
Before carrying out machine parameter teaching (Z-axis origin offset), save the current
machine parameters into a floppy disk. (Programming manual)
Dange
r
Warning
Caution
EJM8A-E-SMA060403-A01-00
Page　6-4-3-1
Remark
Select [Machine parameter] from the main menu.
• The machine-parameter menu screen
is displayed.
Press [Mach prmtr teach].
The "Machine parameter teaching"
screen is displayed.
2
3
(A) When Nozzles 130S are used for all the nozzle positions with the component-thickness sensor (Head-
mounted type) used (Batch teaching):
Item
1
Press [UNLOCK] and [START] on the operation panel.
Option Part and Accessory Replacement
* A component-thickness sensor (head-mounted type) is an option for the high-speed head (12-nozzle type).
The following procedures are applied to the high-speed head (12-nozzle type) only.
Component-Thickness-Measuring Unit
2
1
3
33
EJM8A-E-SMA060403-A01-00
Page　6-4-3-2
Option Part and Accessory Replacement
Component-Thickness-Measuring Unit
Remark
Press [Z-axis origin offset].
Select the table to be taught.
When teaching the Z-axis only:
* Press [ChipThickness] so that it will not
be selected.
When teaching chip thickness only:
* Press [Z axis] so that it will not be
selected.
Press [UNLOCK] on the operation panel and [Jig setting] simultaneously.
Item
6
4
5
Press [UNLOCK] on the operation panel and [Return to origin] simultaneously.
7
4
5
6
7
EJM8A-E-SMA060403-A01-00
Page　6-4-3-3
