Remarks
Component-Thickness-Measuring Unit
Item
Option Part and Accessory Replacement
Check the sensitivity.
Amplifier level value: 2000 or more
Put the FM-1962(2) component-
thickness-sensor-light-axis-adjusting jig
between the sensors. With the light
reduced, check the amplifier level value
is 2000 or more.
* If the value is less than 2000, see 6-4-5
Component-Thickness-Sensor
Replacement.
FM-1962(2) Component-
thickness-sensor-light-
axis-adjusting jig (2.
Component-thickness-
measuring-unit-light-axis-
adjusting jig)
Set the amplifier key lock.
Press the "Manual" and "Mode" buttons
for some seconds at the same time.
Put the cover back on.
35
Phillips screwdriver #2
36
Allen key M6
M6 x 60L ( 2 pcs.)
34
33
Install the component-thickness-sensor unit.
Manual button
Mode button
Install the cover with two M4 screws.
Install it with two M6 x 60L screws.
EJM8A-E-SMA060404-A01-00
Page　6-4-4-10
Remarks
Component-Thickness-Measuring Unit
Item
Option Part and Accessory Replacement
Connect the I/O link cable connector.
37
Connect the amplifier connector.
38
Put the feeder cover back on.
アンプレベル値：２０００以上
Allen key 3 mm
Screw M4 4 pcs.
Turn on the power and air supply.
39
40
1
2
Connect the I/O link cable connector.
Connect the amplifier connector.
EJM8A-E-SMA060404-A01-00
Page　6-4-4-11
• Tools
Phillips screwdriver #2
Allen key Long/Short
Wrench 10 mm
Wrench 12 mm
Nipper
• Jigs
FM-1962(1)
(1. Component-height-
detection-sensor-
adjusting power box)
FM-1962(2)
(2. Component-thickness-
measuring-unit-light-axis-
adjusting jig)
• Necessities
Bushing
KXFB029SA00 (4 pcs.)
Block gauge (10 mm)
Component-Thickness-Measuring Unit
6-4-5 Component-Thickness-Sensor Replacement (8-Nozzle-Head Specifications)
Option Part and Accessory Replacement
This section describes the procedures for replacing the component-thickness sensor (8-nozzle-head spec.).
Bushing Block gauge
Danger
Warning
Caution
FM-1962(1) Component-thickness-measuring-unit-light-axis-
adjusting jig
(1. Component-height-detection-sensor-adjusting power box )
FM-1962(2) Component-thickness-measuring-unit-light-axis-
adjusting jig
(2. Component-thickness-measuring-unit-light-axis-adjusting
j
i
g)
EJM8A-E-SMA060405-A01-00 Page　6-4-5-1
