7 T ra y This chapte r desc ribes t he t ra y . EJM 8A-E- SMAA-0000 Conf ident ial
No. Jig/Tool No. Jig/Tool
12
Adm. code Adm. code
FM-1962(1) FM-1853(1)
Name Name
N610047800AA N610034340AA
No. Jig/Tool No. Jig/Tool
34
Adm. code Adm. code
FM-1853(2) FM-1962(2)
Name
Name
N610034346AA N610019723AA
No. Jig/Tool No. Jig/Tool
56
Adm. code Adm. code
FM-1963 FM-1964
Name Name
N610047825AA N610051789AA
Installation
adjusting jig
Height
measuring jig
Component-
thickness-
sensor-light-
axis-adjusting
jig
Component-
thickness-
measuring-
unit-light-axis-
adjusting jig
Jigs and Inspection Devices
Option Part and Accessory Replacement
Component-
height-
detection-
sensor-
adjusting power
source (without
amplifier)
Component-
height-
detection-
sensor-
adjusting
power
source
EJM8A-E-SMA060601-A01-00 Page 6-6-1-3
