10 11 12 Connect the tray feeder to the machine tentatively. Connect the connector and the Switch ON the power. Allen key 6 mm Screw M8 x 20L 2 pcs. Determine the height of the tray feeder according to the transfer heigh…

100%1 / 1093
When installing the tray on Stage AR,
put the urethane stopper at the front left.
When installing it on Stage BR,
put it at the front right.
machine when seen from the rear side.
Place the drain bottle along with the bracket
on the plate. Extend the tube, using the
joint
and tube.
6
7
8
Fit the guide.
Allen key 5 mm
Screw M6x10L 2 pcs.
5
Place the plate on the right side of the
Place the urethane stopper on the main
Shuttle Tray
Fit the tray holder holding bracket.
RemarksItem
#61020：PLATE
#81040：JOINT, TUBE
Allen key M6
Allen key M4
Screw M5x12L 2 pcs.
Screw M3x10L 2 pcs.
#81020：
URETHANE STOPPER
#81031：BOLT
the tray on Stage AR.
body of the tray.
Move the drain bottle when installing
Allen key 6 mm
Screw M8x30L 2 pcs.
Tray
Tighten them.
Do not tighten
them.
EJM8A-E-SMA070101-A01-00
Page　7-1-1-3
10
11
12
Connect the tray feeder to the machine tentatively.
Connect the connector and the
Switch ON the power.
Allen key 6 mm
Screw M8 x 20L 2 pcs.
Determine the height of the tray feeder according to the transfer height.
air tube.
Open the cover of the tray delivery position.
Item Remarks
Shuttle Tray
9
Level the tray feeder.
Tray
Do not tighten them.
107 mm
When transfer height
is 900 mm
EJM8A-E-SMA070101-A01-00
Page　7-1-1-4
Tray Shuttle Tray
Roughly position the pickup head and the transfer head.
Key disk
Set [Shuttle Tray] to [Use].
14
16
Place the jig on the pickup head.
15
Item Remarks
13
Change the system parameters.
9.5 mm from the
mechanical
stopper
15.0 mm from
the mechanical
stopper
EJM8A-E-SMA070101-A01-00
Page　7-1-1-5
