Tray Shuttle Tray Roughly position the pickup head and the transfer head. Key disk Set [Shuttle Tray] to [Use]. 14 16 Place the jig on the pickup head. 15 Item Remarks 13 Change the system parameters. 9.5 mm from the mec…
10
11
12
Connect the tray feeder to the machine tentatively.
Connect the connector and the
Switch ON the power.
Allen key 6 mm
Screw M8 x 20L 2 pcs.
Determine the height of the tray feeder according to the transfer height.
air tube.
Open the cover of the tray delivery position.
Item Remarks
Shuttle Tray
9
Level the tray feeder.
Tray
Do not tighten them.
107 mm
When transfer height
is 900 mm
EJM8A-E-SMA070101-A01-00
Page 7-1-1-4
Tray Shuttle Tray
Roughly position the pickup head and the transfer head.
Key disk
Set [Shuttle Tray] to [Use].
14
16
Place the jig on the pickup head.
15
Item Remarks
13
Change the system parameters.
9.5 mm from the
mechanical
stopper
15.0 mm from
the mechanical
stopper
EJM8A-E-SMA070101-A01-00
Page 7-1-1-5
Tray
Lower the pickup head.
Remarks
Leveling the pickup head, align it with the transfer head.
Press [Bst shuttle pick up head 1 down] and [Bst shuttle pick up head 2 down].
Feeler gauge: 0.5 mm
20
Wrench 270 mm
Confirm the levelness and tighten the nut.
19
18
17
Item
Shuttle Tray
Gap 0.5 mm
EJM8A-E-SMA070101-A01-00
