Tray Lower the pickup head. Remarks Leveling the pickup head, align it with the transfer head. Press [Bst shuttle pick up head 1 down] and [Bst shuttle pick up head 2 down]. Feeler gauge: 0.5 mm 20 Wrench 270 mm Confirm …
Tray Shuttle Tray
Roughly position the pickup head and the transfer head.
Key disk
Set [Shuttle Tray] to [Use].
14
16
Place the jig on the pickup head.
15
Item Remarks
13
Change the system parameters.
9.5 mm from the
mechanical
stopper
15.0 mm from
the mechanical
stopper
EJM8A-E-SMA070101-A01-00
Page 7-1-1-5
Tray
Lower the pickup head.
Remarks
Leveling the pickup head, align it with the transfer head.
Press [Bst shuttle pick up head 1 down] and [Bst shuttle pick up head 2 down].
Feeler gauge: 0.5 mm
20
Wrench 270 mm
Confirm the levelness and tighten the nut.
19
18
17
Item
Shuttle Tray
Gap 0.5 mm
EJM8A-E-SMA070101-A01-00
Page 7-1-1-6
Install the upper part of the tray feeder to the machine and tighten the bolts.
Re-confirm the levelness. Tighten the bolts that are half tightened.
Item Remarks
Tray Shuttle Tray
24
Carry out machine parameter teaching.
23
Remove the sheet from the transfer
section. Mount the jig.
22
Allen key 4 mm
Bracket
Screw M5x10L 2 pcs.
Allen key 6 mm
Screw M8x40L 2 pcs.
Screw M8x20L 2 pcs.
21
Tighten them.
EJM8A-E-SMA070101-A01-00
Page 7-1-1-7
