Precisely position the transfer and the shuttle heads. 6 7 8 determine the key rsps. Align the shuttle head sensor LED with the holes of the jig, using the inching keys According to how much the shuttle head is out of pl…
Item
3
4
The shuttle head checks
the holes of the jig, and
corrects the pickup position
automatically.
Remove the sheet from the transfer section.
Carry out the machine parameter teaching.
Select [Shuttle]. Press [Pick pos teach].
Press [Offset set].
Offset range:
-5.000 to 5.000
Remarks
Mount the jig.
Tray Shuttle Tray
2
1
EJM8A-E-SMA070102-A01-00
Page 7-1-2-2
Precisely position the transfer and
the shuttle heads.
6
7
8
determine the key rsps.
Align the shuttle head sensor LED with the holes of the jig, using the inching keys
According to how much the shuttle head is out of place,
Remarks
Tray Shuttle Tray
Carry out the "Delivery position" teaching.
Item
Key rsps:
0.01, 0.10, 1.00
as necessary.
5
Press [Offset set].
Offset range: -3.5 to 3.5
Unrelock switch
Inching keys
EJM8A-E-SMA070102-A01-00
Page 7-1-2-3
Offset range: -5.0 to 5.0
10
11
12
Press [Offset set].
Key rsps:
0.01, 0.10, 1.00
Item Remarks
9
Select [Tray side].
Press [Pick pos teach].
Tray Shuttle Tray
Offset for Tray palette
pickup position
Align the shuttle head sensor LED with the holes of the palette extension,
using the inching keys as necessary.
According to how much the shuttle head or the transfer head is out of place,
determine the key rsps.
Unlock switch
Inching keys
EJM8A-E-SMA070102-A01-00
