2 1 90578 Remarks Power down the machine. Phillips precision screwdriver Connector screw Item Shuttle Tray Phillips screwdriver #2 Screw M4 4 pcs. Remove all connectors from the front board. Remove the connector from the…
• Jigs
30
• Tools
None
Phillips screwdriver #2
Precision screwdriver
Nipper
Allen key M4
Teaching
Assembly/AdjustmentRemoval/Disassembly
Lift-axis Driver Replacement
Min.
20 Min.
2.050
0
Min.
kgs
Tray
Min.
Shuttle Tray
This section describes the procedures for replacing the lift-axis driver.
Total Time Part Weight
7-1-5
Dange
r
Warning
Caution
EJM8A-E-SMA070105-A01-00
Page 7-1-5-1
2
1
90578
Remarks
Power down the machine.
Phillips precision
screwdriver
Connector screw
Item
Shuttle Tray
Phillips screwdriver #2
Screw M4 4 pcs.
Remove all connectors from the front board.
Remove the connector from the right side of the box.
3
4
Tray
Remove the front and the side covers from the control box.
EJM8A-E-SMA070105-A01-00
Page 7-1-5-2
Phillips screwdriver #2
Nipper
Cut off the cable ties on the right side.
5
Allen key 4 mm
Screw M5 2 pcs.
Be careful not to let the
cables be caught.
Phillips precision
screwdriver
Connector screws
Open the front cover.
Cut off the front cable ties.
Item
Shuttle Tray
Remarks
Remove the box holding screws.
Pull out the box. Remove the driver connectors.
6
7
8
Tray
Remove the connectors.
EJM8A-E-SMA070105-A01-00
Page 7-1-5-3
