12 34 Remarks 4 Fit the jig on the door switch connector. Allen key 3 mm M4 x 10L 1 pc. Allen key 3 mm Phillips screwdriver #2 M4×8L 3 pcs. M4×10L 2 pcs. M5×15L Truss 2 pcs. Open the cover of the delivery position. Open …

100%1 / 1093
Assembly/AdjustmentRemoval/Disassembly
15
Min. Min.
30
Total Part Weight
Phillips screwdriver #2
Allen key 3 mm
Ruler 150 mm
Ruler 300 mm
kgs.
45
Min.
Connector jig
7-1-7 Shuttle Head Stroke Adjustment
Shuttle Tray
Tools
Tray
・This section describes the procedures for adjusting the stroke of the shuttle head.
I Since this adjustment requires releasing the safety cover switch, only those who are authorized
to release it based on the Document "Key Switch/Key Disk Receipt Confirmation and Safety
Precautions" are permitted to perform this adjustment.
Jigs
Min.
Teaching
Danger
Caution
Warning
EJM8A-E-SMA070107-A01-00
Page　7-1-7-1
12
34
Remarks
4
Fit the jig on the door switch connector.
Allen key 3 mm
M4 x 10L 1 pc.
Allen key 3 mm
Phillips screwdriver #2
M4×8L　　　　　3 pcs.
M4×10L　　　　2 pcs.
M5×15L Truss 　2 pcs.
Open the cover of the delivery position. Open the maintenance door.
Set the machine parameter offset to "0."
Tray
3
Remove the cover holding screws.
Shuttle Tray
2
1
Item
Remove the door switch connector.
Door switch of
Delivery position
EJM8A-E-SMA070107-A01-00
Page　7-1-7-2
Adjustable distance: +/- 3 mm
(The hole is 3-mm long.)
5
Tray Shuttle Tray
(Be sure to keep yourself off the drive section.)
Remarks
If it is necessary to adjust the distance more than 3 mm,
loosen the bolts below and move the belt.
Measure the distance from the dog
Item
Carry out "Return to origin."
6
If it is necessary to adjust the distance, loosen the bolts that are positioned
at the back of the belt clamp, and adjust the distance.
to the mechanical stopper.
Allen key 3 mm
Screw M4 2 pcs.
Allen key 3 mm
Screw M4 2 pcs.
Distance from Dog to
Stopper:
9.5mm±1mm
7
8
3 6.5 36.5(30)
4.5
731.5
727st
－O/R
StrokeOrigin
＋O/R
Mechanical
stopper
Dog
＋soft limit －soft limit
