Tray Shuttle Tray Loosen the belt tension. 8 6 7 Remove and replace the belt. Remarks Item 5 Remove the cover from the motor section. Remove the pickup head belt clamp. Allen key 3 mm M4 2 pcs. Allen key 3 mm M4×8L 3 pcs…
Shuttle TrayTray
1
Remarks
Switch off the power
Allen key 3 mm
Phillips screwdriver #2
M4×8L 8 pcs.
M4×10L Truss 2 pcs.
Allen key 3 mm
Phillips screwdriver #2
M4×8L 3 pcs.
M4×10L 2 pcs.
M5×15L Truss 2 pcs.
2
Allen key 3 mm
M4 x 10L 1 pc.
Open the cover of the delivery position. Open the maintenance door.
Remove the door switch connector.
Remove the cover holding screws.
Item
Remove the top cover.
3
4
Door switch of
Delivery position
EJM8A-E-SMA070108-A01-00
Page 7-1-8-2
Tray Shuttle Tray
Loosen the belt tension.
8
6
7
Remove and replace the belt.
RemarksItem
5
Remove the cover from the motor section.
Remove the pickup head belt clamp.
Allen key 3 mm
M4 2 pcs.
Allen key 3 mm
M4×8L 3 pcs.
M4×10L 2 pcs.
M4×12L 2 pcs.
EJM8A-E-SMA070108-A01-00
Page 7-1-8-3
Tray Shuttle Tray
Adjust the belt tension.
Allen key 3 mm
Allen key 4 mm
Screw M4 2 pcs.
Screw M5 2 pcs.
Allen key 3 mm
Allen key 4 mm
Screw M4 2 pcs.
Screw M5 2 pcs.
Remarks
Replace the belt.
Put the motor shaft holder back on.
Allen key 3 mm
M4 2 pcs.
12
9
Remove the motor shaft holder.
Put the pickup head belt clamp back on.
Loosen the tension and remove the belt.
10
11
Item
Motor shaft holder
EJM8A-E-SMA070108-A01-00
Page 7-1-8-4
