CM602all_EJM8AESM_Service Manual - 第930页
Item Open the cover of the delivery position. Open the maintenance door. Remove the door switch connector. 1 Switch off the power. Remarks Remove the top cover. Allen key 3 mm Phillips screwdriver #2 M4×8L 8 pcs. M4×10L …
Teaching
Tools
Jigs
Min. Min.
25
Connector jig
Phillips screwdriver #2
Allen key 3 mm
Allen key 4 mm
Ruler 150 mm
Ruler 300 mm
kgs.
75
Min.Min.
35
This section describes the procedures for replacing the shuttle head motor.
Total Part Weight
Assembly/AdjustmentRemoval/Disassembly
15
7-1-9 Shuttle Head Motor Replacement
Shuttle TrayTray
Dange
r
Warning
Caution
EJM8A-E-SMA070109-A01-00
Page 7-1-9-1
Item
Open the cover of the delivery position. Open the maintenance door.
Remove the door switch connector.
1
Switch off the power.
Remarks
Remove the top cover.
Allen key 3 mm
Phillips screwdriver #2
M4×8L 8 pcs.
M4×10L Truss 2 pcs.
Remove the cover holding screws.
3
4
Tray Shuttle Tray
Allen key 3 mm
M4 x 10L 1 pc.
2
Allen key 3 mm
Phillips screwdriver #2
M4×8L 3 pcs.
M4×10L 2 pcs.
M5×15L Truss 2 pcs.
Door switch of
Delivery position
EJM8A-E-SMA070109-A01-00
Page 7-1-9-2
Nipper
Allen key 3 mm
M4×8L 3 pcs.
M4×10L 2 pcs.
M4×12L 2 pcs.
Loosen the motor shaft holding screws.
Disconnect the motor connector. Cut off the cable tie.
Allen key 3 mm
Allen key 4 mm
Screw M4 2 pcs.
Screw M5 2 pcs.
Loosen the tension and remove the belt.
Remove the motor shaft holder.
Remarks
Remove the cover from the motor section.
Item
5
6
7
8
Tray Shuttle Tray
Motor shaft holder
EJM8A-E-SMA070109-A01-00
Page 7-1-9-3
