Remove the palette table. 4 3 Shuttle Tray Phillips screwdriver #2 Screw M4 12 pcs. Allen key 2.5 mm M3 8 pcs. Open the cover. Item Phillips screwdriver #2 Allen key 3 mm Screw M4 2 pcs. M4x10L 8 pcs. Remove the top cove…
Tool
Min.
Teaching
10
kgs.
80
Part WeightTotal
30
Extension-Axis Timing Belt Replacement
Jig: FM-0982
Min.
40
Shuttle Tray
This section describes the procedures for replacing the extension-axis timing belt.
Jig
Tray
Removal/Disassembly Assembly/Adjustment
Min. Min.
7-1-11
Dange
r
Warning
Caution
EJM8A-E-SMA070111-A01-00
Page 7-1-11-1
Remove the palette table.
4
3
Shuttle Tray
Phillips screwdriver #2
Screw M4 12 pcs.
Allen key 2.5 mm
M3 8 pcs.
Open the cover.
Item
Phillips screwdriver #2
Allen key 3 mm
Screw M4 2 pcs.
M4x10L 8 pcs.
Remove the top cover.
Switch off the power.
2
1
Remarks
Tray
EJM8A-E-SMA070111-A01-00
Page 7-1-11-2
Remove the belt clamp unit. Replace the belt.
Loosen the tensions at the motor section.
Allen key 3 mm
Screw M4 2 pcs.
After replacing the belt, tighten the belt clamp unit.
Position the belt. Tighten the tensions at the motor section.
Allen key 5 mm
Screw M6 2 pcs.
Item
Allen key 3 mm
Screw M4 2 pcs.
5
Remarks
Shuttle Tray
6
7
8
Tray
EJM8A-E-SMA070111-A01-00
Page 7-1-11-3
