18 Power up the machine. 17 Phillips screwdriver #2 Screw M4 4 pcs. 90578 Put the front and the side covers back on. Item Remarks Tray Shuttle Tray EJM8A-E-SMA070112-A01-00 Page 7-1-12-6
14
Close the front cover. Fix it in place.
16
Phillips precision
screwdriver
Connector screws
Connect all connectors to the front board.
15
Connect the connectors to the right side of the box.
Phillips screwdriver #2
Item Remarks
13
Nipper
Connect the cable connectors on the right side.
Secure the cable ties.
Tray Shuttle Tray
EJM8A-E-SMA070112-A01-00
Page 7-1-12-5
18
Power up the machine.
17
Phillips screwdriver #2
Screw M4 4 pcs.
90578
Put the front and the side covers back on.
Item Remarks
Tray Shuttle Tray
EJM8A-E-SMA070112-A01-00
Page 7-1-12-6
Tray Shuttle Tray
This section describes the procedures for replacing the extension-axis motor.
Extension-axis Motor Replacement7-1-13
Assembly/Adjustment
Min.
Teaching
30
Min.
20 Min.30
2.5
Jig: FM-0982
Phillips screwdriver #2
Allen key 2 mm
Allen key 3 mm
Allen key 4 mm
Pulley remover
Removal/Disassembly
kgs
80
Min.
Total Time Part Weight
Tool
Jig
Dange
r
Warning
Caution
EJM8A-E-SMA070113-A01-00
Page 7-1-13-1
