3 4 Phillips screwdriver #2 Allen key 3 mm Screw M4 2 pcs. M4 x 10L 8 pcs. Phillips screwdriver #2 Screw M4 12 pcs. Shuttle Tray Item 1 Power down the machine. Remove the upper cover. Remarks Open the cover. Remove the m…
Tray Shuttle Tray
This section describes the procedures for replacing the extension-axis motor.
Extension-axis Motor Replacement7-1-13
Assembly/Adjustment
Min.
Teaching
30
Min.
20 Min.30
2.5
Jig: FM-0982
Phillips screwdriver #2
Allen key 2 mm
Allen key 3 mm
Allen key 4 mm
Pulley remover
Removal/Disassembly
kgs
80
Min.
Total Time Part Weight
Tool
Jig
Dange
r
Warning
Caution
EJM8A-E-SMA070113-A01-00
Page 7-1-13-1
3
4
Phillips screwdriver #2
Allen key 3 mm
Screw M4 2 pcs.
M4 x 10L 8 pcs.
Phillips screwdriver #2
Screw M4 12 pcs.
Shuttle Tray
Item
1
Power down the machine.
Remove the upper cover.
Remarks
Open the cover.
Remove the motor connector.
Tray
2
EJM8A-E-SMA070113-A01-00
Page 7-1-13-2
Shuttle Tray
Allen key 4 mm
Screw M5 4 pcs.
6
7
8
aligning it to the D-shaped cut. Tighten it.
Remove the motor from the bracket.
Allen key 2 mm
Setscrew M3 2 pcs.
Remarks
Tray
5
Item
Allen key 4 mm
Screw M5 2 pcs.
Loosen the motor belt tension. Remove the motor.
Remove the motor pulley setscrews. Fit one setscrew on the motor axis,
Remove the pulley.
Replace the motor. Fit the pulley.
Allen key 2 mm
Setscrew M3 2 pcs.
Pulley remover
EJM8A-E-SMA070113-A01-00
Page 7-1-13-3
