Tray Shuttle Tray Carry out the "return-to-origin" operation. With the feeder change cart removed, connect the connector. When the distance is 3 mm or less, loosen the bolt placed on the back of the Item Remark…
Move it along the arrow and
loosen the tension.
Move it along the arrow and
tension the belt.
Tray
Item
Allen key 2.5 mm
M3 4 pcs.
Install the belt clamp for the transfer head.
Remark
Shuttle Tray
Allen key 2.5 mm
M3 2 pcs.
Fix the motor holding bracket in place.
Replace the belt.
Allen key 3 mm
M4 2 pcs.
Allen key 3 mm
M4 2 pcs.
Loosen the motor holding bracket.
8
Remove the belt.
Install the motor holder.
5
6
7
EJM8A-E-SMA070115-A01-00
Page 7-1-15-3
Tray Shuttle Tray
Carry out the "return-to-origin" operation.
With the feeder change cart removed, connect the connector.
When the distance is 3 mm or less, loosen the bolt placed on the back of the
Item Remark
12
Ruler
Stopper ⇒ Dog: 9.5 mm
belt clamp and adjust it.
10
11
9
Allen key 2.5 mm
Screw M3 2 pcs.
Adjustment gap: ±3 mm
Measure the distance between the mechanical stopper and the dog.
5510(22)
3
558
550st
－O/R
StrokeOrigin
＋O/R
Mechanical
stopper
Dog
＋soft limit －soft limit
5
EJM8A-E-SMA070115-A01-00
Page 7-1-15-4
Tray
Item Remark
13
again. Measure the clearance again.
14
Phillips screwdriver #2
Truss screw 4 pcs.
Allen key 2.5 mm
Screw M3 2 pcs.
Shuttle Tray
16
See Section "7-1-2.
Shuttle Tray Teaching."
15
Put the upper cover back on.
Carry out the "return-to-origin" operation
After the adjustment, teach machine parameters.
If it is necessary to adjust the distance more than 3 mm,
loosen the bolts below and move the belt.
22
B
A=550st
(587)
C
D
E
(67)
(8.5)
(46.5)
EJM8A-E-SMA070115-A01-00
Page 7-1-15-5
