Remove the cover holding screws.
To use the shuttle tray, change the cover
When the NAVI system is installed, remove
the power unit from the BR right stage.
Allen key 2.5 mm
To secure space in which the STCV 1
cable is connected.
pull it out along the horizontal arrow.
Remarks
Remove the Y-motor cover from the rear side
.
Hold it along the vertical arrows and
Tray Shuttle Tray
Phillips screwdriver #2
Allen key 3 mm
M4 button head screw 4
pcs.
M4 screw 6 pcs.
Item
Remove the emergency stop button
20
17
and the cover.
Remove the connector screws.
19
18
EJM8A-E-SMA070117-A01-00 Page　7-1-17-6
Layout of Signal Cable 2 to AR Left Ring I/O
Layout of Signal Cable 2 to BR Left Ring I/O
Connect the power cable to the
rear side of the power unit.
Power unit 1 TYR.P1
Power unit 2 TYR.P2
91060:
A stage tray
communication cable 2
91070:
B stage tray
communication cable 2
Tray Shuttle Tray
Connect the transfer unit communication cable.
Remarks
22
23
21
24
Item
Remove the upper side
cover
Secure the cable,
positioning it outside the
frame.
NF0ECX#4
91060
STCV11
NF0ECX#3
91030
STCV1
OUT0
IN1
IN2
STCV21
NF0ECX#7NF0ECX#8
91070
91040
STCV2
OUT0
IN1
IN2
STVC11
IN2/1
OUT0
STVC21
IN2/1
OUT0
EJM8A-E-SMA070117-A01-00 Page　7-1-17-7
Connect the power connector.
Be careful of the direction when
connecting it.
Allen key 2.5 mm
Screw M3 x 8 4 pcs.
Connect the Signal Cable 1 connector.
Be careful of the direction when
connecting it. Allen key 3 mm
Screw M4 x 8 4 pcs.
Connect the signal cable to Power Unit 1.
Connect the signal cable to Power Unit 2.
(2) Standard cables N2 to
N5 are not used.
Shuttle Tray
28
26
25
Tray
Item Remarks
27
(1) Secure the unused
short connector with a
cable tie.
(1) Secure the unused
short connector with a
cable tie.
Tie the cap strap to the upper left screw
as shown at left.
(2) Standard cables N2 to
N5 are not used.
UP
(1)
(2)
R2A+V R2A-V
TRY.EA
N2-N5
R2B+V
R2B-V
TRY.EB
N1-N9
(1)
(2)
UP
