Samsung Intelligent Feeder System
4.4.3. IT Feeder 3 Ass’y
4-8
Specifications And Technical Drawing & PartList
IT Feeder 3 Ass'y
NO. PARTNO. PARTNAME Q'TY TYPE REMARK
1
PIN-GUIDE 4
2
BLOCK-FEEDER 2
3
DOWN SHAFT 2
4
NUT-LOCK 6
5
SPACER 2
6
CYL-BRACKET 1
7
UP/DOWN BAR 1
8
SPACER-CYL. 1
9
PIN-BRACKET 4
10
SHAFT 1
11
BRACKET-STOPPER 1
12
SUPPORT-BODY 1
13
SUPPORT2-BODY 1
14
BRACKET-BODY 1
15
SUPPORT-SIDE 2
16
BRACKET-COVER 4
17
SUPPORT SHAFT-COVER 2
18
BLOCK-HANDLE 2
19
BASE 1
20
HANDLE 2
21
COVER-LM GUIDE 2
22
COVER-LM GUIDE 2
23
COVER-LOWER 1
24
COVER-UPPER 1
25
COVER-SWITCH 1
26
CYLINDER 1 MGPL80-75
4-9
Samsung Intelligent Feeder System
IT Feeder 3 Ass'y
NO. PARTNO. PARTNAME Q'TY TYPE REMARK
27
MECHANICAL VALVE 1 VZM550-01-34R
28
SILENCER 2 AN103-01
29
SPEED CONTROL 3 JSU 6
30
COUPLING 1 CPS 15M-8
31
COUPLING 2 CPP 15-8
32
FITTING 4 PL6-01M
33
FITTING 1 PH8-01
34
35
CASTER 4 NO.102HB2-EP
36
STOPPER 2 K1710-2
37
NIPPLE 2 D-1/8-3/8
38
BEARING 12 SG BR-25
39
SHAFT PIN 6 SG25(Eccentric)
40
SHAFT PIN 6 SG25(non-eccentric)
A1
SPACER ROLLER 4
A2
SHAFT ROLLER 4
A3
HOUSING ROLLER 4
A4
ROLLER 4
4-10
