EUKYX 3-18 199-5100 1.6 Side Panel Front 1 .6 Side Panel F ront 1 .6. 1 Inside of the panel Symbol Name Remarks Q205 CirCuit Protector V acuum pump Q206 CirCuit Protector Q221 CirCuit Protector K29 EM-CONT ACTOR V acuum …
EUKYX
3-17199-5100
1.5 Side View PCB Panel
1.5 Side View PCB Panel
Symbol Name Remarks
U02 Side View I/O PCB Model UC39
G9 Side View Camera Power Unit
U02
G9
16
EUKYX
3-18199-5100
1.6 Side Panel Front
1.6 Side Panel Front
1.6.1 Inside of the panel
Symbol Name Remarks
Q205 CirCuit Protector Vacuum pump
Q206 CirCuit Protector
Q221 CirCuit Protector
K29 EM-CONTACTOR Vacuum pump Power Supply
K28 EM-CONTACTOR CPU Power Supply
K10 EM-CONTACTOR G2 Power Supply
K10K28K29Q205
Q206(30A)
Q221(30A)
TB:AC2
3
EUKYX
3-19199-5100
1.6 Side Panel Front
1.6.2 Side panel Front (Outside)
Symbol Name Remarks
F200 Lightning Surge Protector
TB ： AC1
F200
3
