EUKYX 1-19 199-5100 2.8 Head Unit 2. 8 Head Unit 3 5 4 6 No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty 3 Solenoid V alve 1 4 Rotary Joint 1 5 Solenoid V alve 15 6 Filter 15
EUKYX
1-18199-5100
2.7 Nozzle Stocker
2.7 Nozzle Stocker
9
4
5
6
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
4 Solenoid Valve 1
5 Cylinder 1
6 Cylinder 1
9 Union Y
EUKYX
1-19199-5100
2.8 Head Unit
2.8 Head Unit
3
5
4
6
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
3 Solenoid Valve 1
4 Rotary Joint 1
5 Solenoid Valve 15
6 Filter 15
EUKYX
1-20199-5100
2.9 Feeder Base
2.9 Feeder Base
3
4
2
6
5
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
2 Solenoid Valve 2
3 Speed Controller 4
4 Cylinder 2
5 Modular Unit 2
6 Air Connector Pin 2
