WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
95
ADVANCED PROGRAMMING
Close Clamp at Loop Height
The operator can set up the machine’s loop shape in one of two ways. From the main EDIT LOOP MENU
key G can be pressed and the machine will walk the operator through all of the loop shape settings. Or, if
key 4 is selected, the user can modify each setting individually.
4500E
ONLY
Close CLAMP AT LOOP HT ABOVE Bond #1: n/a
5=Info
9=Next bond
A=Prev option G=Next option
Close CLAMP AT LOOP HT ABOVE Bond #2:
4=Key in 5=Close
7=Prev bond 8=Suggest 9=Next bond
A=Prev option 0=Open G=Next option
ϑ To call “Close Clamp at Loop Height”
From the H
OME menu press 4 (EDIT), 0 (EDIT LOOP MOTION), 4 (LOOP EDIT), and then
press 9 (C
LOSE MODE).
Key Format:
Escape
1
Go To
Device
2
Home
3
4
Close
5
6
Previous
Bond
7
Suggest
8
Next
Bond
9
Previous
Option
A
Open
0
Next
Option
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
96
ADVANCED PROGRAMMING
Close Clamp at Search
The operator can set up the machine’s loop shape in one of two ways. From the main EDIT LOOP MENU
key G can be pressed and the machine will walk the operator through all of the loop shape settings. Or, if
key 4 is selected, the user can modify each setting individually.
4500E
ONLY
Close CLAMP AT SEARCH ABOVE Bond #1: n/a
5=Info
9=Next bond
A=Prev option G=Next option
Close CLAMP AT SEARCH ABOVE Bond #2:
4=Key in 5=Close
7=Prev bond 8=Suggest 9=Next bond
A=Prev option 0=Open G=Next option
ϑ To call “Close Clamp at Search”
From the H
OME menu press 4 (EDIT), 0 (EDIT LOOP MOTION), 4 (LOOP EDIT), 9 (CLOSE
MODE), and then press G (NEXT OPTION).
Key Format:
Escape
1
Go To
Device
2
Home
3
4
Close
5
6
Previous
Bond
7
Suggest
8
Next
Bond
9
Previous
Option
A
Open
0
Next
Option
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
97
ADVANCED PROGRAMMING
Loop Pull
This option “cuts” a 45° angle from the loop height to the work surface. This feature works to lower the
loop height. (5 steps = 1mil)
LOOP PULL before Bond #1: n/a
5=Info
9=Next bond
A=Prev option G=Next option
LOOP PULL before Bond #2: 0 Y step
4=Key in 5=Increase (0.00000”)
7=Prev bond 8=Suggest 9=Next bond
A=Prev option 0=Decrease G=OK
ϑ To call “Loop Pull”
From the H
OME menu press 4 (EDIT), 0 (EDIT LOOP MOTION), 4 (LOOP EDIT), and then
press 0 (LOOP PULL).
Key Format:
Escape
1
Go To
Device
2
Home
3
Key In
4
Increase
5
6
Previous
Bond
7
Suggest
8
Next
Bond
9
Previous
Option
A
Decrease
0
Next
Option
G
