WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
50
ADVANCED PROGRAMMING
Machine Setup Menus
F
OR 4500E AND 4600E MODES ONLY
MACHINE SETTINGS MENU #1
Machine Settings Menu #1
4=Clamp home 5=Wire pull 6= Wire tail
7=Dual force 8=Force adjust 9=Restart ht
A=Prev menu 0=More options G=Sequence
1 = Edit Menu, 3 = Home,
0 = Machine Settings Menu #2
G = Sequence – This will step the operation through
the machine settings of both Menu #1 and Menu #2
ϑ To call “Edit Machine Settings Menu #1”
From the H
OME menu press 4 (EDIT), and then press 6 (MACHINE).
Key Format:
Previous
Menu
1
2
Home
3
Clamp home
4
Wire pull
5
Wire tail
6
Dual force
7
Force adjust
8
Restart
height
9
Previous
Menu
A
More
options
0
Sequence
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
51
ADVANCED PROGRAMMING
Machine Setup Menus
FOR 4500E AND 4600E MODES ONLY
MACHINE SETTINGS MENU #2
Machine Settings Menu #2:
4=Lift-to-pull 5=U/S feed 6=U/S thread
8=U/S test
A=Prev menu G=Sequence
1 = Edit Menu, 3 = Exit Edit,
G = Sequence – This will step the operation through
each of the machine settings; both Menu #1 and
Menu #2
ϑ To call “Edit Machine Settings Menu #1”
From the H
OME menu press 4 (EDIT), 6 (MACHINE), and then press 0 (MORE OPTIONS)
Key Format:
Previous
Menu
1
2
Home
3
Lift-to-pull
4
U/S Feed
5
U/S thread
6
7
U/S Test
8
9
Previous
Menu
A
0
Sequence
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
52
ADVANCED PROGRAMMING
Machine Setup Menus
FOR 4700E MODE ONLY
MACHINE SETTINGS MENU #1
Machine Settings Menu #1
4=Clamp home 5=Wire tail 6=Ball fault
7=Dual force 8=Force adjust 9=Restart ht
A=Prev menu 0=More options G=Sequence
1 = Edit Menu, 3 = Home,
0 = Machine Settings Menu #2
G = Sequence – This will step the operation through
the machine settings of both Menu #1 and Menu #2
ϑ To call “Edit Machine Settings Menu #1”
From the H
OME menu press 4 (EDIT), and then press 6 (MACHINE).
Key Format:
Previous
Menu
1
2
Home
3
Clamp home
4
Wire tail
5
Ball
Fault
6
Dual force
7
Force adjust
8
Restart
height
9
Previous
Menu
A
More
options
0
Sequence
G
