WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
55
ADVANCED PROGRAMMING
Wire Pull
FOR 4500E AND 4600E MODES ONLY
This option allow the operator to increase or decrease the distance the clamp blades pull back to break
the wire after the termination bond. The suggested settings are 34 for 45° and 30 for 90° applications is
displayed on the menu. The numerical selection defines the number of motor steps. To increase the
clamp pull stroke, increase the “Wire Pull” number. Excessive wire pull may cause the wire to become
unthreaded. To change the selected number, use the “4” key to key data, or the “5” key to increase, or the
“0” key to decrease.
WIRE PULL (See ϑ below or G was pressed from Edit Clamp Home Menu).
Wire Pull: 34 steps
4=Key in 5=Increase
8=Suggest
A=Prev option 0=Decrease G=Next option
Program in A motor half-steps.
8 = Restore after suggestion is made.
ϑ To edit “Wire Pull”
From the H
OME menu press 4 (EDIT), 6 (MACHINE), and then 5 (WIRE PULL)
Key Format:
Previous
Menu
1
2
Home
3
Key in
4
↑
Increase
5
6
7
Suggest
8
9
Previous
option
A
↓
Decrease
0
Next
option
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
56
ADVANCED PROGRAMMING
Wire Tail
This option allows the operator to increase or decease the length of the tail: meaning the wire length
offered for view prior to performing the first bond. The suggested settings of 24 steps for 45° (4500E), 35
steps for 90° (4600E), and 60 steps for 90° ball (4700E) applications are displayed on the menu. The
numerical selection defines the number of motor steps. To increase the tail length, increase the tail
number. To change the selected number, use the “4” key to key data, or the “5” key to increase, or the “0”
key to decrease.
WIRE TAIL (See ϑ below or G was pressed from Edit Wire Pull Menu)
Wire Tail: 24 steps
4=Key in 5=Increase
8=Suggest
A=Prev option 0=Decrease G=Next option
60 steps is the suggested setting for 4700E
Program in A motor half-steps.
8 = Restore after suggestion is made.
ϑ To edit “Wire Tail”
F
OR 4500E AND 4600E MODES ONLY
From the H
OME menu press 4 (EDIT), 6 (MACHINE), and then 6 (WIRE TAIL)
ϑ To edit “Wire Tail”
F
OR 4700E MODE ONLY
From the H
OME menu press 4 (EDIT), 6 (MACHINE), and then 5 (WIRE TAIL)
Key Format:
Previous
Menu
1
2
Home
3
Key in
4
↑
Increase
5
6
7
Suggest
8
9
Previous
option
A
↓
Decrease
0
Next option
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
57
ADVANCED PROGRAMMING
Ball Fault
FOR 4700E MODE ONLY
When the B
ALL FAULT DETECTION is turned on, the machine will detect a short or open condition in relation
to the torch wand and the gold wire. The factory suggests that the BALL FAULT DETECTION setting be left
on.
Ball Fault Detection: On
5=On
8=Suggest
A=Prev option 0=Off G=Next option
ϑ To edit “Ball Fault”
From the H
OME menu press 4 (EDIT), 6 (MACHINE), and then 6 (BALL FAULT)
Key Format:
Previous
Menu
1
2
Home
3
4
On
5
6
7
Suggest
8
9
Previous
option
A
Off
0
Next option
G
