WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
62
ADVANCED PROGRAMMING
Lift Before Pull
FOR 4500E AND 4600E MODES ONLY
To change the selection of this feature press the “5” key for ON or the “0” key for OFF option. The
454647E will wait until the Tooling Head has lifted off the terminating bond site before actuating the pull
stroke if this feature is selected to “ON”. The suggested setting is “OFF”. This feature can prove
beneficial for those applications in which the terminating bond is made on delicate or sensitive
components, or for applications with extremely soft wire.
LIFT BEFORE PULL (Display this menu if 45° feed tool is in use.)
Lift Before Pull: Off
5=On
8=Suggest
A=Prev option 0=Off G=Next option
LIFT BEFORE PULL (Display this menu if 90° feed tool is in use.)
Lift Before Pull: 6 (1Z= .0002083”)
4=Key in 5=Up
8=Suggest
A=Prev option 0=Down G=Next option
To edit “Lift Before Pull”
From the H
OME menu press 4 (EDIT), 6 (MACHINE), 0 (MORE OPTIONS), then 4 (LIFT-TO-PULL).
Key Format:
Previous
Menu
1
2
Home
3
4
On
5
6
7
Suggest
8
9
Previous
option
A
Off
0
Next option
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
63
ADVANCED PROGRAMMING
Ultrasonic Power During Feed
The number entered controls the amount of ultrasonic energy applied to the tool during the feeding of the
wire. This ultrasonic energy is critical in assisting vertical feed bonding tools. The 45° tools usually do not
benefit from ultrasonic during feed. If this setting is increased to too high a setting, it may actually shake
the wire out of the tool. If this setting is set so that it exceeds the “Ultrasonic Power during Thread” (see
next page), then the power during thread will be increased to make them equal.
ULTRASONIC POWER DURING FEED
Ultrasonic Power During Feed: 400
4=Key in 5=Increase
8=Suggest
A=Prev option 0=Decrease G=Next option
Normally used only for 90° applications
To edit “Ultrasonic Power During Feed”
F
OR 4500E AND 4600E MODES ONLY
From the H
OME menu press 4 (EDIT), 6 (MACHINE), 0 (MORE OPTIONS), then 5 (U/S FEED)
To edit “Ultrasonic Power During Feed”
F
OR 4700E MODE ONLY
From the H
OME menu press 4 (EDIT), 6 (MACHINE), 0 (MORE OPTIONS), then 4 (U/S FEED)
Key Format:
Previous
Menu
1
2
Home
3
Key in
4
↑
Increase
5
6
7
Suggest
8
9
Previous
option
A
↓
Decrease
0
Next option
G
WEST•BOND MODEL 454647E SERIES INSTRUCTION MANUAL
64
ADVANCED PROGRAMMING
Ultrasonic Power During Thread
Similar to the Ultrasonic power during feed option, except that this ultrasonic power level is used during
the long clamp stroke (Executed by pressing key “6” from the thread and bond-off menu). The values
suggested by the 454647E are the same as those for the ultrasonic power during feed option. The
454647E will reject values that are lower than the power during feed.
ULTRASONIC POWER DURING THREAD
Ultrasonic Power During Thread: 400
4=Key in 5=Increase
8=Suggest
A=Prev option 0=Decrease G=Next option
Normally used only for 90° applications
To edit “Ultrasonic Power During Thread”
F
OR 4500E AND 4600E MODES ONLY
From the H
OME menu press 4 (EDIT), 6 (MACHINE), 0 (MORE OPTIONS), and then 6 (U/S THREAD)
To edit “Ultrasonic Power During Thread”
F
OR 4700E MODE ONLY
From the H
OME menu press 4 (EDIT), 6 (MACHINE), 0 (MORE OPTIONS), and then 5 (U/S THREAD)
Key Format:
Previous
Menu
1
2
Home
3
Key in
4
↑
Increase
5
6
7
Suggest
8
9
Previous
option
A
↓
Decrease
0
Next option
G
